Chapter 3
3-8
c-2. LEVEL 3
Moving the printer on its end
Transporting in low temperature environment such as subzero
Transportation procedure
1) If there is a message instructing to replace the maintenance cartridge or check the remaining ink, replace the maintenance cartridge.
2) Remove the paper and roll holder.
3) From [Main menu] > [Maintenance] > [MOVE PRINTER], select [LEVEL 2] or [LEVEL 3].
4) Press the [OK] key and perform [LEVEL 2] or [LEVEL 3] of [MOVE PRINTER].
5) If the counter is checked and a message to replace consumable parts appear, check the consumable parts counter from service mode and replace the necessary
consumable part.
See "d. Replacing consumable parts during transportation."
Repeat [LEVEL 2] or [LEVEL 3] after replacing consumable parts and resetting the counter.
6) Follow the displayed message and open the left and right ink tank covers.
F-3-11
Item Description
[MOVE PRINTER] on the Main menu Perform [LEVEL 3].
Allowed tilting angle Lengthwise: -90 to +90 degrees
Rotation: -30 to +30 degrees
Ink consumption Approximately 700ml of ink is consumed.
Ink tank Remove all ink tanks.
Separation of main unit and stand Separate.
Maintenance cartridge Replace with new maintenance cartridge before performing transporting procedure.
Three new maintenance cartridges must be provided.
(Two for disposing waste ink and one to be installed new maintenance cartridge during transportation)
Replacement of consumable parts Replacement of consumable parts and resetting of counter may be necessary.
Service support If consumable parts must be replaced, service support is necessary.
To Next Page
