Canon imagePROGRAF iPF815 Service Manual

Chapter 7
7-16
7.1.4 Sample Printout
0020-5737
a) PRINTINF
A sample printout that is produced by executing [SERVICE MODE] > [DISPLAY] > [PRINTINF] is shown below, along with instructions about how to interpret it.
F-7-1
(1) Version numbers of the firmware installed in the printer, boot ROM, and MIT DB format
(2) Printer information
For more item details, see "Detail of Service Mode" > "a) Display".
(3) Counter information
For more item details, see "Detail of Service Mode" > "e) Counter".
(a) Consumables status
(b) Number of days elapsed since the counter was last reset
(c) Counter value
(d) Value with which consumables reach their replacement timing
(e) Ratio of the current count to the replacement timing
(f) Cumulative counter value
(4) Ink saver mode setting
(a) Ink saver mode status
(b) Number of times ink save mode has been executed (unit: times).
xxxx PRINT INF
Firm:00.49 Boot:00.31 MIT(DBF):9303 MIT(DB):1.02 S/N:DF029090
SYSTEM
TYPE:DF029090 24 0 TMP:26 SIZE_LF: 0.0 SIZE_CR: 514.3
HEAD S/N:39410000
HEAD LOT:166L09A0
INK
C :0 M :0 Y :0 MBK :0MBK2 :0 BK :0
WARNING
01:0000 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
ERROR
01:03060A00-2E01 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
INK CHK: C:0 M:0 Y:0 MBK:0 MBK2:0 BK:0
COUNTER
PRINTER
LIFE TTL:0
LIFE ROLL:0 LIFE CUTSHEET:0
LIFE A:0 B:0 C:0 D:0 E:0 F:0
MEDIA 7 MEDIA OTHER
NAME : NAME : OTHER
TTL : 0.0 m2 0.0 sq.f TTL : 0.0 m2 0.0 sq.f
ROLL : 0.0 m2 0.0 sq.f ROLL : 0.0 m2 0.0 sq.f
CUTSHEET : 0.0 m2 0.0 sq.f CUTSHEET : 0.0 m2 0.0 sq.f
PARTS COUNTER
COUNTER A : OK 36
PARTS A1 : 0.0 36.1 0% 0.0
PARTS A2 : 0.0 36.1 0% 0.0
COUNTER D : OK 36
PARTS D1 1362 13028571 0% 1362
PARTS D2 : 377 6700000 0% 377
PARTS D3 : 2238 16500000 0% 2238
COUNTER F : OK 36
PARTS F1 : 377 4000000 0% 377
COUNTER H : OK 36
PARTS H1 : 15 50000 0% 15
COUNTER K : OK 36
PARTS K1 : 4 12500 0% 4
COUNTER M : OK 36
PARTS M1 : 0 750 0% 0
PV AUTO JUDGE : ON(NORMAL) , 1
(1)
(2)
(3)
(a) (b) (c) (d) (e) (f)
(4)
(a) (b)

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
