Chapter 6
6-11
T-6-27
J3401
Pin Number Signal name IN/OUT Function
1 VMGND - GND
2 VMGND - GND
3 VMGND - GND
4 VMGND - GND
5 VH_MONI1 IN VH controll signal 1
6 VH_ENB OUT VH power supply ON/OFF signal
7 VH_MONI2 IN VH controll signal 2
8 GND - GND
9 +3.3V OUT Power supply(+3.3V)
10 +3.3V OUT Power supply(+3.3V)
11 GND - GND
12 SNS5V OUT Power supply(+5V)
13 SNS5V OUT Power supply(+5V)
14 VM OUT Power supply(+32V)
15 VM OUT Power supply(+32V)
16 VM OUT Power supply(+32V)
17 VM OUT Power supply(+32V)
18 VM OUT Power supply(+32V)
19 VM OUT Power supply(+32V)
20 VM OUT Power supply(+32V)
21 VM OUT Power supply(+32V)
22 VMGND - GND
23 VMGND - GND
24 VMGND - GND
25 VMGND - GND
