Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-16
T-6-35
32 /H1-E-HE-9 OUT Head(L) heat enable signal 9(E)
33 GND - GND
34 H1-F-DATA-10-EV OUT Even head(L) data signal 10(F)
35 GND - GND
36 H1-F-DATA-11-EV OUT Even head(L) data signal 11(F)
37 GND - GND
38 /H1-F-HE-11 OUT Head(L) heat enable signal 11(F)
39 GND - GND
40 H1-F-DATA-11-OD OUT Odd head(L) data signal 11(F)
41 GND - GND
42 H1-F-DATA-10-OD OUT Odd head(L) data signal 10(F)
43 GND - GND
44 /H1-F-HE-10 OUT Head(L) heat enable signal 10(F)
45 GND - GND
46 H1-E-DATA-9-OD OUT Odd head(L) data signal 9(E)
47 GND - GND
48 H1-E-DATA-8-OD OUT Odd head(L) data signal 8(E)
49 GND - GND
50 /H1-E-HE-8 OUT Head(L) heat enable signal 8(E)
J102
Pin Number Signal name IN/OUT Function
1 GND - GND
2 VH1 2 OUT Power supply
3 VH2 (Feedback) IN VH2 feed back voltage
4 VH2 OUT Power supply
5 VH2 OUT Power supply
6 VH2 OUT Power supply
7 VH2 OUT Power supply
8 VH2 OUT Power supply
9 VH2 OUT Power supply
10 GND - GND
11 GND - GND
12 GND - GND
13 GND - GND
14 GND - GND
15 VH1 OUT Power supply
16 VH1 OUT Power supply
17 VH1 OUT Power supply
18 VH1 OUT Power supply
19 VH1 OUT Power supply
20 VH1 OUT Power supply
21 VH1 (Feedback) IN VH2 feed back voltage
22 GND - GND
23 GND - GND
24 H3V 1 Power supply
25 GND - GND
26 PWLED4 OUT Multi sensor LED4 drive signal
27 PWLED3 OUT Multi sensor LED3 drive signal
28 PWLED2 OUT Multi sensor LED2 drive signal
29 PWLED1 OUT Multi sensor LED1 drive signal
30 GND -
J203
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
