Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-18
T-6-37
43 H1-C-DATA-4-OD OUT Odd head(L) data signal 4(C)
44 GND - GND
45 MLT_SENS_1IN IN Multi sensor signal 1
46 GND - GND
47 MLT_SENS_2IN IN Multi sensor signal 2
48 GND - GND
49 SNS5V OUT Power supply(+5V)
50 GND - GND
J102
Pin Number Signal name IN/OUT Function
1 /H1-E-HE-8 OUT Head(L) heat enable signal 8(E)
2 GND - GND
3 H1-E-DATA-8-OD OUT Odd head(L) data signal 8(E)
4 GND - GND
5 H1-E-DATA-9-OD OUT Odd head(L) data signal 9(E)
6 GND - GND
7 /H1-F-HE-10 OUT Head(L) heat enable signal 10(F)
8 GND - GND
9 H1-F-DATA-10-OD OUT Odd head(L) data signal 10(F)
10 GND - GND
11 H1-F-DATA-11-OD OUT Odd head(L) data signal 11(F)
12 GND - GND
13 /H1-F-HE-11 OUT Head(L) heat enable signal 11(F)
14 GND - GND
15 H1-F-DATA-11-EV OUT Even head(L) data signal 11(F)
16 GND - GND
17 H1-F-DATA-10-EV OUT Even head(L) data signal 10(F)
18 GND - GND
19 /H1-E-HE-9 OUT Head(L) heat enable signal 9(E)
20 GND - GND
21 H1-E-DATA-9-EV Even head(L) data signal 9(E)
22 GND - GND
23 H1-E-DATA-8-EV OUT Even head(L) data signal 8(E)
24 GND - GND
25 /H1-D-HE-7 OUT Head(L) heat enable signal 7(D)
26 GND - GND
27 H1-D-DATA-7-EV OUT Even head(L) data signal 7(D)
28 GND - GND
29 H1-D-DATA-6-EV OUT Even head(L) data signal 6(D)
30 GND - GND
31 /H1-D-HE-6 OUT Head(L) heat enable signal 6(D)
32 GND - GND
33 H1-D-DATA-6-OD OUT Odd head(L) data signal 6(D)
34 GND - GND
35 H1-D-DATA-7-OD OUT Odd head(L) data signal 7(D)
36 GND - GND
37 H1-C-DATA-5-OD OUT Odd head(L) data signal 5(C)
38 GND - GND
39 /H1-C-HE-5 OUT Head(L) heat enable signal 5(C)
40 GND - GND
41 H1-C-DATA-5-EV OUT Even head(L) data signal 5(C)
42 GND - GND
43 H1-C-DATA-4-EV OUT Even head(L) data signal 4(C)
44 GND - GND
45 /H1-B-HE-3 OUT Head(L) heat enable signal 3(B)
46 GND - GND
47 H1-B-DATA-3-EV OUT Even head(L) data signal 3(B)
48 GND - GND
49 /LIFT CAM IN - GND
50 GND - GND
J103
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
