T-6-40
30 H0-F-DIA2 IN Head(R) DI sensor signal 2(E)
31 H0-E-HE-9 OUT Head(R) heat enable signal 9(E)
32 H0-D-DATA-7-EV OUT Even head(R) data signal 7(D)
33 H0-D-HE-6 OUT Head(R) heat enable signal 6(D)
34 H0-C-DATA-5-OD OUT Odd head(R) data signal 5(C)
35 H0-C-DATA-4-EV OUT Even head(R) data signal 4(C)
36 H0-A-DATA-1-EV OUT Even head(R) data signal 1(A)
37 H0-A-DIA2 IN Head(R) DI sensor signal 2(A)
38 H0-B-DIA2 IN Head(R) DI sensor signal 2(B)
39 H0-C-HE-4 OUT Head(R) heat enable signal 4(C)
40 H0-D-DATA-7-OD OUT Odd head(R) data signal 7(D)
41 H0-E-DATA-8-OD OUT Odd head(R) data signal 8(E)
42 H0-F-HE-10 OUT Head(R) heat enable signal 10(F)
43 H0-F-DATA-11-EV OUT Even head(R) data signal 11(F)
44 H0-E-DATA-8-EV OUT Even head(R) data signal 8(E)
45 H0-D-DATA-6-EV OUT Even head(R) data signal 6(D)
46 H0-C-DIA2 IN Head(R) DI sensor signal 2(C)
47 H0-C-DATA-5-EV OUT Even head(R) data signal 5(C)
48 H0-B-DIA1 IN Head(R) DI sensor signal 1(B)
49 H0-A-HE-0 OUT Head(R) heat enable signal 0(A)
50 H0-B-DATA-2-OD OUT Odd head(R) data signal 2(B)
51 H0-B-DATA-3-OD OUT Odd head(R) data signal 3(B)
52 H0-C-DATA-4-OD OUT Odd head(R) data signal 4(C)
53 GND - GND
54 GND - GND
55 GND - GND
56 H0-F-DATA-11-OD OUT Odd head(R) data signal 11(F)
57 H0-E-DATA-9-EV OUT Even head(R) data signal 9(E)
58 GND - GND
59 H0-D-DATA-6-OD OUT Odd head(R) data signal 6(D)
60 H0-C-HE-5 OUT Head(R) heat enable signal 5(C)
61 H0-B-HE-3 OUT Head(R) heat enable signal 3(B)
62 H0-A-DIA1 IN Head(R) DI sensor signal 1(A)
63 H0-A-DATA-1-OD OUT Odd head(R) data signal 1(A)
64 GND - GND
65 GND - GND
66 GND - GND
67 GND - GND
68 H0-F-DATA-10-OD OUT Odd head(R) data signal 10(F)
69 H0-F-DIA1 IN Head(R) DI sensor signal 1(F)
70 H0-D-HE-7 OUT Head(R) heat enable signal 7(D)
71 GND - GND
72 H0_CLK OUT Head(R) clock signal
73 H0_LT OUT Head(R) latch signal
74 H0-B-DATA-2-EV OUT Even head(R) data signal 2(B)
75 H0-A-DATA-0-OD OUT Odd head(R) data signal 0(A)
76 GND - GND
77 GND - GND
78 GND - GND
J201
Pin Number Signal name IN/OUT Function
1 PWLED1 OUT Multi sensor LED1 drive signal
2 PWLED2 OUT Multi sensor LED2 drive signal
3 PWLED3 OUT Multi sensor LED3 drive signal
4 PWLED4 OUT Multi sensor LED4 drive signal
5 GND - GND
6 MLT_SNS_1 IN Multi sensor signal 1
7 MLT_SNS_2 IN Multi sensor signal 2
8 Vcc(5V) OUT Power supply (+5V)
J104
Pin Number Signal name IN/OUT Function
