Canon imagePROGRAF iPF815 Service Manual

Chapter 7
7-7
T-7-6
First Level Second Level Third Level Fourth Level Fifth Level
COUNTER HEAD DOT CNT. 1 C
---
BK
TTL
HEAD DOT CNT. 2 C
---
BK
TTL
PARTS CNT. COUNTER A OK/W1/W2/E
PARTS A1 1:00
2:00
3:00
4:00
---
COUNTER Y OK/W1/W2/E
PARTS Y1 1:00
2:00
3:00
4:00
SETTING Pth ON/OFF
RTC DATE yyyy/mm/dd
TIME hh:mm
PV AUTO JUDGE ON/OFF
HEAD DOT INF ON/OFF
INITIALIZE WARNIG : Press the [OK] button to clear
ERROR : Press the [OK] button to clear
ADJUST : Press the [OK] button to clear
W-INK : Press the [OK] button to clear
CARRIAGE : Press the [OK] button to clear
PURGE : Press the [OK] button to clear
INK-USE CNT : Press the [OK] button to clear
W-INK-CHG CNT : Press the [OK] button to clear
HEAD-CHG CNT : Press the [OK] button to clear
HDD BOX PASS. ALL FOLDERS : Press the [OK] button to
clear
FOLDER 1 : Press the [OK] button to
clear
---
FOLDER 29 : Press the [OK] button to
clear
PARTS-CHG CNT PARTS A PARTS A1 : Press the [OK]
button to clear
---
PARTS Y1 : Press the [OK]
button to clear
PARTS COUNTER PARTS A PARTS A1 : Press the [OK]
button to clear
---
PARTS Y1 : Press the [OK]
button to clear

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
