Canon imagePROGRAF iPF815 Service Manual

Chapter 7
7-11
d) COUNTER
Displays the life (operation frequency and time) of each unit, print counts for each media type, and else.
The count values can be printed from [PRINT INF].
1) PRINTER: Counters related to product life
2) CARRIAGE: Counters related to carriage unit
3) PURGE: Counters related to purge unit
4) CLEAR: Counters related to counter initialization
Display Description Unit
LIFE TTL Cumulative number of printed media (equivalent of A4) sheets
LIFE ROLL UPPER Cumulative number of printed upper roll media (equivalent of A4) sheets
LIFE ROLL LOWER Cumulative number of printed lower roll media (equivalent of A4) sheets
LIFE CUTSHEET Cumulative number of printed cut sheets (equivalent to A4) sheets
LIFE A-F Cumulative number of printed media for environments A to F sheets
POWER ON Cumulative power-on time (excluding the sleep time) Hours
W-INK Remaining capacity of the maintenance cartridge %
CUTTER Number of cutting operations (count as 1 by moving back and forth) Times
WIPE Number of wiping operations Times
Display Description Unit
PRINT Cumulative printing time Hours
DRIVE Cumulative carriage moving time Hours
CR COUNT Cumulative carriage scan count (count as 1 by moving back and forth) Times
CR DIST. Cumulative carriage scan distance (count as 1 by moving 210mm) Times
PRINT COUNT Cumulative print end count (count as 1 by capping) Times
Display Description Unit
CLN-A-1 Cumulative number of automatic cleaning 1 (normal suction) operations Times
CLN-A-2 Cumulative number of automatic cleaning 2 (ink level adjusting) operations Times
CLN-A-3 Cumulative number of automatic cleaning 3 (initial filling) operations Times
CLN-A-6 Cumulative number of automatic cleaning 6 (strong normal suction) operations Times
CLN-A-7 Cumulative number of automatic cleaning 7 (aging) operations Times
CLN-A-10 Cumulative number of automatic cleaning 10 (ink filling after secondary transportation) operations Times
CLN-A-11 Cumulative number of automatic cleaning 11 (ink filling after head replacement) operations Times
CLN-A-15 Cumulative number of automatic cleaning 15 (dot count small suction) operations Times
CLN-A-16 Cumulative number of automatic cleaning 16 (sedimented ink agitation) operations Times
CLN-A-17 Cumulative number of automatic cleaning 17 (small suction) operations Times
CLN-A-TTL Total number of automatic cleaning operations Times
CLN-M-1 Cumulative number of manual cleaning 1 (normal suction) operations Times
CLN-M-4 Cumulative number of manual cleaning 4 (ink draining from head after head replacement) operations Times
CLN-M-5 Cumulative number of manual cleaning 5 (ink draining from head and tube before transportation ) operations Times
CLN-M-6 Cumulative number of manual cleaning 6 (normal strong suction) operations Times
CLN-M-TTL Total number of manual cleaning operations Times
Display Description Unit
CLR-INK CONSUME Cumulative count of ink section consumption amount clearing Times
CLR-MTC EXC. Cumulative count of maintenance cartridge replacement count clearing Times
CLR-HEAD EXC. Cumulative count of printhead replacement count clearing Times
CLR-UNIT A EXC. Cumulative count of unit A(waste ink system) replacement count clearing Times
CLR-UNIT D EXC. Cumulative count of unit D(carriage unit) replacement count clearing Times
CLR-UNIT H EXC. Cumulative count of unit H(purge unit) replacement count clearing Times
CLR-UNIT K EXC. Cumulative count of unit K(head management sensor) replacement count clearing Times
CLR-UNIT M EXC. Cumulative count of unit M(carriage motor) replacement count clearing Times
CLR-UNIT P EXC. Cumulative count of unit P(feed motor) replacement count clearing Times
CLR-UNIT S EXC. Cumulative count of unit S(upper pick-up roller) replacement count clearing Times
CLR-UNIT T EXC. Cumulative count of unit T(lower pick-up roller) replacement count clearing Times
CLR-UNIT V EXC. Cumulative count of unit V(mist fan unit) replacement count clearing Times
CLR-UNIT Y EXC. Cumulative count of unit Y(cutter) replacement count clearing Times
CLR-FACTORY CNT. For factory Times

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
