Canon imagePROGRAF iPF815 Service Manual

Chapter 7
7-13
10) MEDIA x (x: 1 to 7): Counters related to media
One to seven media types are displayed individually in order with large cumulative print area.
11) MEDIA OTHER: Counters related to media
Displays the total amount of cumulative print area of the other media type than the above-mentioned
12) MEDIASIZE1 ROLL: Counters related to roll media printing
13) MEDIASIZE2 ROLL: Counters related to roll media printing
Display Description Unit
NAME Media type -
TTL Total amount of cumulative print area of roll media and cut sheet (metric) m2
TTL Total amount of cumulative print area of roll media and cut sheet (inch) Sq.f
ROLL UPPER Cumulative print area of upper roll media (metric) m2
ROLL UPPER Cumulative print area of upper roll media (inch) Sq.f
ROLL LOWER Cumulative print area of lower roll media (metric) m2
ROLL LOWER Cumulative print area of lower roll media (inch) Sq.f
CUT SHEET Cumulative print area of cut sheet (metric) m2
CUT SHEET Cumulative print area of cut sheet (inch) Sq.f
Display Description Unit
NAME Media type -
TTL Total amount of cumulative print area of roll media and cut sheet (metric) m2
TTL Total amount of cumulative print area of roll media and cut sheet (inch) Sq.f
ROLL UPPER Cumulative print area of upper roll media (metric) m2
ROLL UPPER Cumulative print area of upper roll media (inch) Sq.f
ROLL LOWER Cumulative print area of lower roll media (metric) m2
ROLL LOWER Cumulative print area of lower roll media (inch) Sq.f
CUT SHEET Cumulative print area of cut sheet (metric) m2
CUT SHEET Cumulative print area of cut sheet (inch) Sq.f
Display Description Unit
P-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (physical size) m2/Sq.f
P-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (physical size) m2/Sq.f
P-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (physical size) m2/Sq.f
P-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (physical size) m2/Sq.f
P-SQ -17 Cumulative print area of paper less than 17 inches (physical size) m2/Sq.f
P-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(physical size)
sheets
P-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(physical size)
sheets
P-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(physical size)
sheets
P-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(physical size)
sheets
P-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (physical size) sheets
Display Description Unit
D-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size) m2/Sq.f
D-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size) m2/Sq.f
D-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size) m2/Sq.f
D-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size) m2/Sq.f
D-SQ -17 Cumulative print area of paper less than 17 inches (data size) m2/Sq.f
D-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60
inches (data size)
sheets
D-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44
inches (data size)
sheets
D-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36
inches (data size)
sheets
D-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24
inches (data size)
sheets
D-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size) sheets

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
