Canon IMAGERUNNER 2530 User Manual

7
7
7-13
7-13
Error Code > Jam Code > DADF-AA1
Error Code > Jam Code > DADF-AA1
DADF-AB1
PI10
PI11
PI7
PI6
PI8
PI7
PI6
PI11
PI8
F-7-3F-7-3
ACC ID Jam Code Type Sensor Name Sensor ID
4 0003 Delay jam
Registration sensor PI8
4 0004 Stationary jam
Registration sensor PI8
4 0005 Delay jam
Read sensor PI7
4 0006 Stationary jam
Read sensor PI7
4 0007 Delay jam
Delivery reversal sensor PI6
4 0008 Stationary jam
Delivery reversal sensor PI6
4 0044 Stationary jam
(rst document)
Registration sensor PI8
4 0045 Delay jam
(rst document)
Read sensor PI7
4 0046 Stationary jam (rst
document)
Read sensor PI7
4 0047 Delay jam (rst
document)
Delivery reversal sensor PI6
4 0048 Stationary jam
(rst document)
Delivery reversal sensor PI6
4 0071 Timing error
- -
4 0090 ADF open jam
Copyboard cover open/closed
Sensor 0
S21
4 0091 User ADF open jam
Copyboard cover open/closed
Sensor 0
S21
4 0092 ADF cover open jam
Cover open/closed sensor PI10
4 0093 User cover open jam
Cover open/closed sensor PI10
4 0094 Initial stationary jam
Registration sensor or Read
sensor or Delivery reversal sensor
PI6, PI7, PI8
4 0095 Pickup NG
Document set sensor PI11
T-7-6T-7-6

Canon IMAGERUNNER 2530 Specifications

General

Functions	Print, Copy, Scan
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Warm-up Time	30 seconds or less
Multiple Copy	Up to 999 copies
Interface	USB 2.0, Ethernet
Type	Monochrome Laser
Print Resolution	600 x 600 dpi
Copy Speed	Up to 30 ppm (A4)
Network Connectivity	Ethernet
Paper Input (Standard)	250 sheets
Paper Output	100 sheets
Paper Sizes	A4, A5, B5, Legal, Letter, Executive
Paper Weight	64 to 90 g/m²
First Copy Out Time	6.4 seconds or less
Zoom	25-400%
Scan Speed	25 ipm
Scan to	USB
Print Speed (Black)	Up to 30 ppm (A4)
