1.2.4 Cutter
0023-1309
The cutter attached to the cutter unit is a round cutter.
F-1-4
1.2.5 Roll Holder
0023-1308
The roller holder accepts paper tubes having inside diameters of both 2 and 3 inches. It is furnished with attachments for 2- and 3-inch diameter paper tubes.
The roll holder clamps the paper tube of a roll not exceeding 150 mm in outside diameter from the inside.
F-1-5
[2-inch paper tube attachment]
F-1-6
[3-inch paper tube attachment R]
F-1-7
[3-inch paper tube attachment L]
F-1-8
