Chapter 1
1-9
1.4 Detailed Specifications
1.4.1 Interface Specifications
0023-2577
a. USB (standard)
(1) Interface type
USB 2.0 Hi-Speed (Full speed (12 Mbits/sec), High speed (480 Mbits/sec))
(2) Data transfer system
Control transfer
Bulk transfer
(3) Signal level
Compliant with the USB standard.
(4) Interface cable
Twisted-pair shielded cable, 5.0 m max.
Compliant with the USB standard.
Wire materials: AWG No.28, data wire pair (AWF: American Wire Gauge)
AWG No.20 to No.28, power distribution wire pair
(5) Interface connector
Printer side: Series B receptacle compliant with USB standard
Cable side: Series B plug compliant with USB standard
b. Network (standard)
(1) Interface type
Interface compliant with IEEE802.3
(2) Data transfer system
IEEE802.0 10Base-T, IEEE802.3u 100Base-TX/Auto-Negotiation, IEEE802.3ab 1000Base-T/Auto-Negotiation, IEEE802.3x Full Duplex
(3) Interface cable
Operation panel LCD (160 X 128 dots), 13 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead PF-04
Structure: Integrated six-color assembly
Number of nozzles: 5,120 for MBK, 2,560 for other each color
Ink tank [PFI-107/8107] MBK, BK, C, M, Y
[PFI-207/8207] MBK, BK, C, M, Y
Ink type: Pigment ink (MBK)
Dye ink (BK, C, M, Y)
Ink tank capacity: [PFI-107/8107] 130 ml
[PFI-207/8207] 300 ml
(Ink tanks supplied with the printer contain 90 ml of each color.)
Detection functions (Cover
system)
Upper cover open/closed detection: Yes
Ink tank cover open/closed detection: Yes
Detection functions (Ink passage
system)
Ink tank presence/absence detection: Yes
Remaining ink level detection (dot count and electrode): Yes
Maintenance cartridge presence/absence detection: Yes
Used ink tank full detection: Yes
Ink supply Valve open/closed detection: Yes
Detection functions (Carriage
system)
Printhead presence/absence detection: Yes
Carriage position detection: Yes
Carriage home position detection: Yes
Printhead temperature detection: Yes
Printhead height detection: Yes
Non-discharging nozzle detection: Yes
Non-discharging nozzle backup feature: Yes
Ambient temperature/humidity detection: Yes
Detection functions (Paper path
system)
Paper presence/absence detection: Yes
Paper width detection: Yes
Skew detection: Yes
Paper leading edge and trailing edge detection: Yes
Release lever position detection: Yes
Remaining roll media detection: Yes
Feed roller rotation detection: Yes
Roll holder rotation detection: Yes
Cutter position detection: Yes
Operating noise Operating: Approx. 48dB (A) or less
Standby: Approx. 35dB (A) or less
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 140 W
Power consumption In power save (sleep) mode:
4W or less
During standby: 0.5W or less
Printer unit dimensions
(WxDxH)
1304mm(W) x 887mm(D) x 1062mm(H) (with ST-34 stand and opening
the output stacker)
1304mm(W) x 1100mm(D) x 1062mm(H) (with ST-34 stand and setting
to the extended position B)
Weight Approx. 68.1 kg (with stand and without printhead and ink tank)
