Canon iPF780 Series - Page 285

2-9
33 QC3-1649-000 1 CAP, ROLL, RIGHT
34 QC3-1651-000 1 FLAG, SENSOR
35 QC3-1652-000 1 ARM, SENSOR FLAG
36 QL2-3175-000 1 SOLENOID
37 QK1-2081-000 1 MOTOR, STEPPING
38 WG8-5776-000 1 PHOTO-INTERRUPTER, SG2481
39 QU1-2449-000 1 SPRING, TENSION
40 QU1-2450-000 1 SPRING, COMPRESSION
41 QM3-7911-000 1 HARNESS, WIRE, ROLL
42 QM3-4602-000 1 HARNESS, WIRE, MOTOR
43 QM3-5887-020 1 ROLL COVER UNIT
44 QC3-1706-000 1 GUIDE, SLIDE
45 QC3-1707-000 1 LOCK, SLIDE GUIDE
46 WT2-5694-000 3 CLIP CLAMP, WIRE
47 XA9-1386-000 10 SCREW, RS, M3X8
48 RK2-2884-000 1 ENVIRONMENT SENSOR PCB ASS'Y
49 QM3-5870-000 1 GEAR UNIT
50 XA9-1928-000 AR SCREW, TP, M3X8
51 QU1-2456-000 1 SPRING, TORSION
52 QC3-1650-010 1 HOLDER, SENSOR FLAG
501 XB1-2300-409 4 SCREW, MACHINE M3X4
502 XB4-5401-007 19 SCREW, M4X10
503 XD2-1100-502 2 RETAINING RING (E-TYPE)
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
