2-11
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
Fig.04 NPN RF ELECTRICAL PART
1 QM3-5820-010 1 MAIN CONTROLLER ASS'Y iPF750
1 QM3-5819-010 1 MAIN CONTROLLER ASS'Y iPF755
1 QM4-8159-000 1 MAIN CONTROLLER ASS'Y iPF760
1 QM4-8160-010 1 MAIN CONTROLLER ASS'Y iPF765
1 QM7-7289-000 1 MAIN CONTROLLER ASS'Y iPF780
1 QM7-7319-000 1 MAIN CONTROLLER ASS'Y iPF781
1 QM7-7290-000 1 MAIN CONTROLLER ASS'Y iPF785
1 QM7-7320-000 1 MAIN CONTROLLER ASS'Y iPF786
2 QK1-5141-000 1 POWER SUPPLY ASS'Y
3 FK2-2416-000 1 HDD, WD800BEVT-22ZCT0 iPF755(80GB)
3 WM2-5278-000 1 HDD, MK1676GSX(HDD2J96QSL) iPF755(160GB)
3 WM2-5280-000 1 HDD, MK2575GSX(HDD2L05QSL) iPF765(250GB)
3 WM2-5285-000 1 HDD, MQ01ABF032 iPF786/785(320GB)
4 XA9-1928-000 AR SCREW, TP, M3X8
5 WT2-5694-000 3 CLIP CLAMP, WIRE
6 WT2-5738-000 7 CLAMP, CABLE
7 QM3-4585-020 1 HARNESS, WIRE, LEFT iPF765/760/755/750
7 QM7-7296-000 1 HARNESS, WIRE, LEFT iPF786/785/781/780
8 QM3-4587-000 1 HARNESS, WIRE, RIGHT iPF765/760/755/750
8 QM7-7297-000 1 HARNESS, WIRE, RIGHT iPF786/785/781/780
9 FC7-7556-000 2 SADDLE, WIRE
10 QK1-5080-000 1 HARNESS, WIRE, HDD iPF765/755
11 QM3-4582-000 1 HARNESS, INLET
501 XB1-2300-407 4 SCREW, MACH, TRUSS HEAD, M3X4 iPF765/755
502 XB1-2400-607 1 SCREW, CROSS-RECESS, FCH
503 XD1-4200-402 1 WASHER, TOOTHED LOCK, M4
