2-19
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
Fig.07 NPN RF CARRIAGE UNIT
1 QC3-1751-000 1 COVER, PROTECTION
2 QM3-5833-000 1 PULLEY UNIT
3 QU1-2441-000 1 SPRING, COMPRESSION
4 QC3-1531-000 1 RETAINER, PULLEY
5 QC3-1532-000 1 HOLDER, FLEXIBLE CABLE
6 QC3-1533-000 1 COVER, FLEXIBLE CABLE
7 QC3-1534-010 1 GUIDE, FLEXIBLE CABLE
8 QM3-5883-020 1 COVER LOCK UNIT
9 QC3-1684-000 1 PLATE, SWITCH
10 QC3-1686-010 1 LEVER, LOCK
11 QL2-3175-000 1 SOLENOID
12 QU1-2451-000 1 SPRING, TENSION
13 QC3-1621-000 1 SUPPORT, TUBE
14 QL2-3203-000 1 GUIDE, TUBE
15 QM3-5951-010 1 INK TUBE UNIT
16 QC1-0008-000 2 JOINT LEVER B
17 QE1-2819-010 1 JOINT LEVER A
18 QU1-2445-000 1 SPRING, TENSION
19 QM3-5824-020 1 CARRIAGE UNIT iPF765/760/755/750
19 QM4-8458-000 1 CARRIAGE UNIT iPF786/785/781/780
21 QC3-1524-000 1 COVER, LINEAR ENCODER
22 QM3-4574-000 1 ENCODER SENSOR UNIT
23 QC3-1526-000 1 BELT, CARRIAGE
24 QU1-2438-000 1 SPRING, TENSION
25 QM3-5826-010 1 HEAD LEVER UNIT
26 QM3-5831-000 1 MULTI SENSOR UNIT
27 QC3-1515-000 2 RETAINER, PAD
28 QC3-1514-000 4 PAD
29 QC3-1511-000 2 SLIDER, RAIL
30 QU1-2439-000 4 SPRING, TENSION
31 QM3-4569-010 1 CARRIAGE PCB UNIT iPF765/760/755/750
