2-32
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
Fig.R1 NPN RF STAND UNIT ST-33
1 QC3-1914-000 1 BASKET
2 QM3-5894-000 1 SUPPORT ROD UNIT
3 QC3-1739-000 2 SUPPORT, ROD
4 QC3-1492-000 2 GUIDE, BASKET
5 QC2-4346-000 2 JOINT, ROD
6 QM3-5898-000 3 PAPER GUIDE UNIT
7 QC3-1746-000 3 PAPER STOPPER UNIT
8 QC3-1731-000 1 BOX, ACCESSORY
9 QC2-9785-000 2 HOOK, BASKET
10 QC3-1732-000 4 CAP, STAND
11 QD1-1095-000 4 CASTER, W/STOPPER
12 QC2-4116-000 1 SCREW, HEX SOCKET M4X10
13 QC1-5141-000 16 SCREW,ALLEN,M8X20
14 QC2-5993-000 4 SCREW, HEX SOCKET, M4X30
15 QC3-0133-000 2 SCREW, STEPPED, M4
16 QC3-1747-000 1 ROD, STOPPER 36
17 QC3-1442-000 1 ROD, AL 36
18 QC3-1455-000 2 ROD, SIDE AL
19 QC2-6323-010 2 SUPPORT, ROD
20 QD1-0005-000 1 HOLDER, ROD, R
21 QD1-0004-000 1 HOLDER, ROD, L
22 AY3-4573-000 1 ROD SUPPORT KIT, R
23 AY3-4574-000 1 ROD SUPORRT KIT, L
501 XB7-2301-009 4 NUT
502 XB4-5300-807 12 SCREW, P, M3X8
