Chapter 2
2-40
T-2-18
T-2-19
J4201 (Feed motor)
Pin Number Signal name IN/OUT Function
1 LF_OUTB(LF_AP) OUT Feed motor driver signal B
2 LF_OUTA(LF_AM) OUT Feed motor driver signal A
J4501 (Valve motor (L), Upper cover lock solenoid, Cutter left position sensor, Cutter motor, Mist fan)
Pin Number Signal name IN/OUT Function
1 INKBEN_L_OUTB OUT Valve motor (L) drive signal B
2 INKBEN_L_OUTA OUT Valve motor (L) drive signal A
3 VM_26V(26.5V) OUT Power supply (+26.5V)
4 DCOVER_SOL OUT Upper cover lock solenoid drive signal
5 SNS3V_FU1 OUT Power supply (+3.3V)
6 GND - GND
7 CUTTER_L_SNS* OUT Cutter left position sensor signal
8 CUTTERM_OUTB OUT Cutter motor driver signal B
9 CUTTERM_OUTA OUT Cutter motor driver signal A
10 VM_26V OUT Power supply (+26V)
11 MIST_FAN_LOCK* OUT Mist fan drive signal
12 N.C.(MIST_FAN_PWM) - N.C
13 GND - GND
14 N.C. - N.C
To Next Page
