8 times Print head
temperature rise error
[5200] (1) Print head condition (face surface and
mold):
If a burn mark or heat deformation
is seen on the face surface or the
mold, replace the print head.
(2) Head contact pin condition of the
carriage unit:
If the pin is bent or deformed,
replace the carriage unit.
(3) Cable connection:
- CR FFC (J500, J501, J502)
Re-connect the cable.
If any damage or breakage of the
cable is found, replace the carriage
unit.
- Print head
- Carriage unit
9 times EEPROM error [6800]
[6801]
(1) Part replacement:
Replace the logic board ass'y.
- Logic board ass'y
10 times VH monitor error [B200] (1) Print head condition (face surface and
mold):
If a burn mark or heat deformation
is seen on the face surface or the
mold, replace the print head and the
logic board in set. (Be sure to
replace them at the same time.)
(2) Burn mark or heat deformation of the
logic board:
If a burn mark or heat deformation
is seen on the logic board, replace
the print head and the logic board in
set. (Be sure to replace them at the
same time.)
(3) Head contact pin condition of the
carriage unit:
If the pin is bent or deformed,
replace the carriage unit.
(4) Cable connection:
- CR FFC (J502, J501, J500)
Re-connect the cable.
If any damage or breakage of the
cable is found, replace the carriage
unit.
- Print head and logic
board ass'y (replace
them at the same
time)
- AC adapter
- Carriage unit
11 times Carriage lift
mechanism error
[5110] (1) Foreign material that obstructs the
carriage movement:
Remove foreign material.
- Switch system unit
- Carriage unit
12 times APP position error [6A80] (1) Cap absorber and wiper blade of the
purge drive system unit:
If the cap absorber contacts the
- Purge drive system
unit
- Logic board ass'y
