Canon MX882 - Grease Application

3-5. Grease Application
1 drop = 9 to 18 mg
No Part name Where to apply grease / oil
Drawing
No.
Grease
Grease
amount
(mg)
Number
of drops
x
Location
1 Carriage rail
The surface where the carriage unit
slides
(1)
Floil
KG107A
230 to 290 ---
2 Carriage rail
The surface where the carriage unit
slides
(2)
Floil
KG107A
180 to 220 ---
3 Carriage rail
The surface where the carriage unit
slides
(3)
Floil
KG107A
180 to 220 ---
4 Main chassis
The surface where the carriage unit
slides
(4)
Floil
KG107A
230 to 290 ---
5
APP code wheel
gear shaft
APP code wheel gear sliding portion
(the entire surface)
(5)
Floil
KG107A
9 to 18 1 x 1
