*1: Install the Service Tool to a pre-registered computer.
LCD language
settings
To set the language to be displayed
on the LCD.
Not necessary when the machine is
set to the default at shipment from
the production site (On arrival at
user's, the user is to set the language
during setup.).
- At logic board replacement
Set the language in the user
mode.
1 min.
Platen glass
protection sheet
(document pressure
sheet) position
adjustment
To maintain scanning accuracy, hold
the sheet with the long side down,
then fit its upper left corner to the
platen glass reference mark (back
left).
- At protection sheet replacement
- At document pressure plate unit
replacement
- At scanner unit replacement
In the user mode:
(1) Without any document
on the platen glass,
perform copying.
(2) Confirm that no black
streaks are on the
printout.
1 min.
LF / Eject correction To correct line feeding when
necessary.
- At paper feed roller replacement
- At platen unit replacement
- At logic board replacement
- At LF / EJ slit film replacement
- At timing slit film replacement
Service Tool
*1
,
(1) In the LF/EJECT
Correction section,
click Print to print the
LF/EJ correction pattern.
(2) According to the printed
pattern, set the
correction value in the
LF/EJECT Correction
section.
5 min.
Carriage rail position
adjustment
To set the carriage rail to the original
position prior to removal or
replacement of the carriage unit and
maintain the head-to-paper distance,
put a mark on the main chassis before
removal of the carriage unit.
Put a mark using a sharp-
pointed metallic stick, such
as a wimble.
1 min.
FAX user data
settings
To confirm the FAX user data
settings.
- At logic board replacement
- At NCU board replacement
Perform settings in the user
mode.
2 min.
- The screws securing the paper feed motor may be loosened only at replacement of the paper
feed motor unit.
- For the automatic print head alignment, use Matte Photo Paper (MP-101), which is packed
with the machine before shipment. If Matte Photo Paper (MP-101) is not available, perform
manual print head alignment using plain paper.
48 / 76
