CHAPTER 2 BASIC OPERATION
2-3
C. Basic Sequence of Operations (A4, 2 copies)
Figure 2-101C
Sequence
Copyboard
1
2
3
4
5
6
7
8
10
STBY INTR
CBRV STOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Scanning lamp
(LA1-LA8)
Primary AC
bias
Primary DC
bias
Transfer
charging
Copyboard drive
solenoid (SL2)
Pick-up
solenoid *
Registration
solenoid **
Fixing heater
(H1)
Copy paper inserted (PC400/FC200)
Copy Start key ON
Copy paper inserted (PC400/FC200)
2 sec
9
Registration
roller
*PC420/430/FC220
**PC400/FC200
