CHAPTER 5 PICK-UP/FEEDING SYSTEM
5-7
B. Delivery Stationary Jam
The copy paper does not move past the delivery sensor within a specific period of
time.
1. PC420/430/FC220
Sequence
Copyboard
1
2
3
4
5
STBY INTR
CBRV STOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Copyboard posi-
tion sensor (Q902)
Jam check
Copy Start key ON
Pick-up sensor
(Q131)
Delivery sensor
(Q801)
4 sec
errornormal
4 sec
normal
6.5 sec
Sequence
Copyboard
1
2
3
4
5
STBY INTR
CBRVSTOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Copyboard posi-
tion sensor (Q902)
Jam check
Copy paper inserted
Pick-up sensor
(Q131)
Delivery sensor
(Q801)
4 sec
errornormal
4 sec
normal
6.5 sec
Copy paper inserted
Figure 5-401B (A4)
2. PC400/FC200
Figure 5-402B (A4)
