Canon PC420 - Pick-Up;Feeding Timing Chart

COPYRIGHT © 1998 CANON INC. CANON PC400/420/430,FC200/220 REV.0 JAN.1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 5 PICK-UP/FEEDING SYSTEM
5-5
B. Pick-Up/Feeding Timing Chart (A4, 2 copies)
a. PC420/430/FC220
Sequence
Copyboard
1
2
3
4
5
6
STBY INTR
CBRV STOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Copyboard position
sensor (Q902)
Copyboard drive
solenoid (SL2)
Fixing heater
(H1)
Pick-up
solenoid (SL1)
Copy Start key ON
Pick-up sensor
(Q131)
: ON, only PC430.
Figure 5-301B
b. PC400/FC200
Sequence
Copyboard
1
2
3
4
5
6
STBY INTR
CBRV STOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch
Main motor
(M1)
Copyboard position
sensor (Q902)
Copyboard drive
solenoid (SL2)
Fixing heater
(H1)
Registration
solenoid (SL1)
Copy paper inserted*
Pick-up sensor
(Q131)
Copy paper inserted*
*Pick-up sensor (Q131) detects copy paper.
Figure 5-302B
