Cleaning the Protrusions inside the Machine

Important

Be sure to turn off the power and disconnect the power plug before cleaning the

machine.

You need to prepare: cotton swab

If the protrusions inside the machine are stained, wipe off any ink from the protrusions using

a cotton swab or the like.
