Canon PIXMA E414 - Rear View

To Next Page

To Previous Page

Rear View

(1) power cord connector

Plug in the supplied power cord.

(2) USB port

Plug in the USB cable to connect the machine with a computer.

Important

Do not touch the metal casing.

Do not plug in or unplug the USB cable while the machine is printing or scanning

originals with the computer.
