Back panel
The back panel houses the connection for the safety control as well as the connection for
the network cable. This connector has safety fuses.
Also located in the back panel are the air inlets for the ventilators: they are covered by a
safety grid.
Figura 4. Back panel
1.- On/off switch.
2.- Mains cord connector with safety fuses.
3.- Equipment ID sticker
4.- Safety control connector.
1
3
2
4
1
3
2
4
