Ducted version
Turn the motor to evacuate the air from the upper side of the hood. Open the glass
panels, and remove grease filters and carbon filters.
Remove the four screws shown in picture 4. Remove the lower stainless steel as
shown in picture 5. Then remove the screws holding the motor, as shown in picture
6. Open the hole in the middle of the upper side hood (fig 7.) Fix the plug to the
hole where there was the motor before, using the four screws provided. (fig 9)
Install the motor in the upper side by means of the four screws earlier removed
(picture 10). Prearrange an asir outlet exactly in the middle of the hood. Continue
with the installation as Recirculating version (Free standing).
The use of carbon filters is not necessary in this case.
Installtion of the air outlet with a joint diameter of 200mm.
Connect the internal motor or the external motor’s cable to the terminal board
found inside the plastic box of the wiring. Make sure to respect the colors of cables
when performing the electrical connection (fig.2.1)
Make the opening for the air outlet diameter of 200mm on the upper side of the
product (the opening is already marked on the body of the unit).
Install the joint with a diameter of 200mm supplied with the external motor and fix
it with the 8 screws supplied.
The 200mm diameter joint is moved slightly from the longitudinal axis of the
product by 25mm.
