Instruction manual CE1122
Please keep this instruction manual for future reference
12
Make the electicial connection into the metal box.
The power supply metal box is positioned close to the electrical components and
you can see them after removing the grease filters.
Please connect the cables as you can see in picture 18.
Ducting is not supplied with the product, this is to be supplied by the installer
depending on the installation requirements.
If you have selected the output air from the short side of the hood, it is possible to
facilitate the attachment of the tube by removing the cover shown in Fig. 16.
The use of carbon filters is not necessary in this case.
The false ceiling (plasterboard) must remain above the wider part of the
hood fig.13. Make a structure able to support the weight of the false ceiling
(plasterboard), which must not burden the hood.
Recirculating version
After the installation of the hood as described in the previous chapter, connect a
pipe from the motor to the outer part of the niche. Make the electrical connection
into the metal box. Refit the grease filters, the carbon filters (fig.17) and close the
glass panel.
