Turbine Output Submenu
System Data 1/4
Engine LOAD OK 2/10
68.4 kW Gen
The second line shows the engine generator state, and whether the engine is OK or in a
fault condition (FLT). This submenu also gives individual generator output as “kW Gen” on
the third line. Note that in High Efficiency Mode, engine generator power that is greater
than what is required to support the load output will be export to the Grid LCM and/or
supplied to the DC bus.
The engine state messages are abbreviations of the actual engine states, as summarized
in Table 5.
Table 5. Hybrid UPS Engine State Messages and Description
Hybrid UPS
Engine State
Microturbine
Display
Description
STAND BY STB Engine ready to start
LIFT OFF LIFT Engine rotation started
LIGHT OFF LITE Engine ignition started
ACCEL ACEL Engine accelerating to idle
LOAD LOAD Engine ready to output power to load
COOLDOWN CDWN
Stop command issued and engine in cool
down state
WARMDOWN WDWN
Stop command issued and engine in
warm down state
RELIGHT RLIT
Engine commanded to light off again
before rotation stops
SETDOWN SETD Engine rotation stopped
SHUTDOWN SDWN
Engine is shutdown and transitioning to
standby state
