System Demand Submenu
System Data 1/4
System Demand 6/10
0.0 kW
The System Demand submenu allows the user to view, and in certain cases set the Power
Demand in kW when it is operating in High Efficiency Mode. Normally the System Power
Demand value will be determined by the UPS Controller, and will be displayed on this
submenu. Note that to change this value from the Display Panel, the Hybrid UPS system
must be MultiPac disabled and the user must be logged in with the current password.
Control Access Submenu
System Data 1/4
Control Access 7/10
Maintenance Port
The Control Access submenu displays which communication device currently has control
authority for changing settings of the MicroTurbine.
• Display Panel
• User Port
• Maintenance Port
Enter Password Submenu
System Data 1/4
Enter Password 8/10
********
The Enter Password submenu allows the user to logon and access the MicroTurbine
controls. The factory default User-level password is 87712370. Refer to the previous
section on passwords for more details on entering and changing passwords.
Logoff Submenu
System Data 1/4
Logoff 9/10
NO
The Logoff submenu allows the user to logoff and prevents further access to the
MicroTurbine controls. Note that the system will automatically logoff if there is no user
interaction with the Display Panel for more than four minutes.
