Capstone Turbine Corporation
Model C65 Hybrid UPS User’s Manual
Page
52 of 66 400027 Rev A (July 2010)
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
Unit Data Menu
The submenus in the Unit Data menu display real-time data for the MicroTurbine.
Descriptive labels and data are contained in the second, third, and fourth lines of the
submenu. As in all Display Panel submenus, the first line indicates the top-level menu, in
this case the Unit Data menu. Real-time data can also be accessed using CRMS.
The Display Panel submenus related to Unit Data menu are listed below.
NOTE
In the following submenus, the first line always displays the Unit Data top
level menu.
Submenu / Function Description
1/20 System State / Fault Status System State / Fault Status
2/20 Engine State / Fault Status Turbine Generator State / Fault Status
3/20 Utility / Load kW kW Input from Utility and Output to Load
4/20 Utility / Load Frequency Frequency of Utility and Load Connections
5/20 Utility / Load Volts A Voltage Phase A of Utility and Load
6/20 Utility / Load Volts B Voltage Phase B of Utility and Load
7/20 Utility / Load Volts C Voltage Phase C of Utility and Load
8/20 Utility / Load Amps A Current Phase A of Utility and Load
9/20 Utility / Load Amps B Current Phase B of Utility and Load
10/20 Utility / Load Amps C Current Phase C of Utility and Load
11/20 TET / RPM Turbine Exit Temp (°C or °F)/ Engine Speed (RPM)
12/20 Fuel Pressure / Fuel % Fuel Pressure / Fuel Percentage
13/20 Bat Voltage / Bat Current Battery Voltage / Battery Current
14/20 Bat SOC / Last EQ Charge Battery State of Charge / Last Equalization Date
15/20 Inlet Temp Inlet Air Temperature (°C or °F)
16/20 C65 Main Code / Version C65 Main Software Version Code
17/20 CHP Wtr In Tmp ICHP Water Inlet Temperature
18/20 CHP Wtr Out Tmp ICHP Water Outlet Temperature
19/20 CHP Temp Fdbk ICHP Temperature Feedback
20/20 Hours / Starts Turbine Running Time / Number of Starts
Below is an example display for a MicroTurbine showing the main software version.
Unit Data 4/4
C65 Main Code 16/20
SW Ver 1.03
527968-001 C08
