Operating the Capsule Neuron [Chapter 3]
17
English
View from the bottom
3/4 view from the back
5
6
7
8
10
9
Serial ports (4) - front-accessible
USB ports (2) - front-accessible
USB ports (2) - rear-accessible
Serial port (1) - rear-accessible
Ethernet connection
DC power-in connector
5
6
7
8
9
10
5
6
7
8
10
9
Serial ports (4) - front-accessible
USB ports (2) - front-accessible
USB ports (2) - rear-accessible
Serial port (1) - rear-accessible
Ethernet connection
DC power-in connector
