Operating the Capsule Neuron [Chapter 3]
16
3
English
Operating the Capsule Neuron
Components on the Capsule Neuron
Legends on the drawings
In the legend for the drawings that follow:
• Individual components keep the same numbers on each drawing. For example, the USB ports on
the bottom of the Capsule Neuron are shown with the number . When you see the number ,
you know that it represents only these ports.
• Colors have meaning. A blue circle indicates a medical-grade connector. A yellow circle
indicates network connection (Ethernet). All other components are indicated with red circles.
View from the front
6
6
Light sensor
Touch screen
Status LED
RFID badging area
Serial ports
USB ports
1
2
3
4
5
6
1
2
3
5
6
4
