Device Identification Module (DIM) technical specifications
DIMs do not require an external power supply and use standard DB9 and RJ45 connections. The
Device ID Module is a medical grade product compliant with IEC 60601-1 requirements.
Device ID Module P/N B1-DIM-CT-01
Features • Provides Automatic Device Identification
•DB9 Serial Port Input
• RJ45 Serial Port Output
• Powered from the Capsule Neuron, Terminal Server, or
DTS and RTS lines
Dimensions • Length: 69 mm (2.7 inches)
• Width: 38 mm (1.5 inches)
• Height: 22 mm (0.9 inches)
• Weight: 50 grams (1.76 ounces)
Power requirements • +/- 6V output voltage
• 3 to 8 milliamp power consumption
Temperature • Operating: 0° C - 55° C (32° F to 130° F)
• Storage: -30° C to +85° C (-22° F to +185° F)
Relative humidity • Operating: 0 to 99% non-condensing
• Storage: 0 to 99% non-condensing
Atmospheric pressure • Operating: 700 hPa to 1060 hPa
• Storage: 500 hPa to 1060 hPa
Certifications • EN60601-1, EN60601-1-2
•CE Marking, RoHS-compliant
