Setting up the Capsule Neuron
What’s in this chapter
Follow the instructions in this chapter to setup the Capsule Neuron. Deployment follows these
steps, in this order:
• Unpacking and inspecting the package contents
• Installing the batteries in the Capsule Neuron
• Deploying the Capsule Neuron
• Mounting the Capsule Neuron on the wall
• Mounting the Capsule Neuron on a roll stand
• Connecting the Capsule Neuron to the power supply
• Before you use the Capsule Neuron for the first time
Note: This document does not describe the configuration of the Capsule Neuron on a local network.
Refer to the DataCaptor System Administrator's Guide.
Unpacking and inspecting the package contents
Before you install the Capsule Neuron in a clinical setting, you must inspect and set it up according
to instructions.
Contents of a product shipment
The table describes the contents of a Capsule Neuron shipment.
Item Shipment characteristics
Capsule Neuron In one carton, you find the Capsule Neuron itself, wrapped in plastic and
sandwiched between two blocks of polyethylene foam. Each Capsule
Neuron is shipped along with:
• Main battery
The main battery is in position inside the Capsule Neuron, but the
battery pins are not yet in contact with the battery socket on the
Capsule Neuron, and the battery is not yet fixed in place.
•Power brick
The power brick is shipped wrapped in plastic.
• Screws and washers
Four M4 Phillips-head screws and their associated washers are
shipped in a plastic bag with the Capsule Neuron. These screws are
available for attaching the Capsule Neuron to a mounting bracket,
depending on the deployment selected.
