X/Z+ Box
This box contains all the items listed in the table
below and shown in Figure1‑5.
Item Description Qty
A
Z-Plus Carriage with Z-Axis
Stepper Motor and Z-Axis
Proximity Switch
1
B X-Axis Stepper Motor 1
C
M5 × 10mm Socket Head Cap
Screw
4
D
Tramming Plate and Hardware:
M5 × 8mm Socket Head Cap

5
Sweepy Box


Figure1‑6.
Aluminum Extrusion Rails
Examine the three rails, shown in Figure1‑7, and
identify the following:
• X-Axis Rail (X-Rail): has Shapeoko/warning

M4 threaded screw holes along the back.
• Y-Axis Left Rail (Y1-Rail): is plain.
• Y-Axis Right Rail (Y2-Rail):
threaded screw holes along one side.
Endplates
Figure1‑8.


formed and that it is seated squarely in place.
MDF Baseplate


in Figure1‑9.
Carbide Compact Router
Box
Optional Equipment. If you ordered the Carbide

Figure1‑10.
Precision collets, 0.25″ and 0.125″, are included
in the box in addition to the standard router
accessories and tools.
WARNING: MDF is sensitive to moisture.
Avoid liquids and/or high humidity. If you are
in a high-humidity environment, consider
sealing the MDF baseplate with a suitable
nish, such as spar urethane or lacquer.
NOTE: Save the two long foam packing blocks
from the X/Z+ box. We will use them to support
the gantry during assembly.
Figure1-6
Figure1-7
Figure1-5 Figure1-8
Figure1-9
Figure1-10
