Carbide 3D SHAPEOKO 3 - Step 2 Baseframe

Step 2
Baseframe
12 docs.carbide3d.com support@carbide3d.com 13
Required Components
See Figure2‑2:
Item Description Location Qty
A Endplate N/A 2
B  N/A 1
C  Shapeoko 3 Final Assembly Box 4
D M5 × 25mm Button Head Cap Screw Shapeoko 3 Final Assembly Box 12
Required Tools
See Figure2‑3:
Item Description Qty
A 3mm Hex Key 1
B  1
Recommended Tools
See Figure2‑3:
Item Description Qty
C Tape Measure 1
Figure2-2
Figure2-3
