Carel Clima User Manual

21
ENG
clima +030220641 - rel. 1.0 - 07.12.2007
5.5 (T2 + H) two-stage temperature and
humidity control
This is used in applications with two outputs dedicated to temperature
control to send a start signal to an air-conditioner or heat pump/boiler
with two steps. The analogue output is for humidi cation control when
the controller is in heating mode. If the controller is in cooling operation,
humidity control is disabled, and if attempting to change the set point the
lock symbol is shown.
Dipswitch con guration:
dip1: ON
dip2: OFF
dip3: ON
Control is available in both cooling and heating (dip4).
dFH
dSA
% U.R
Output
Set point umidifica
dS1 dS1
Temp.
Output
Temp
Output
Set point inverno Set point estate
dIFdF2 dIFdF2
R1
R1
R2
R2
Fig. 5.h
Temperature and humidity control mode when LE=2.
Parameters involved:
Code Description Default LE
Value or link
if LE = 1
day set point in cooling 24.0 °C 1 -
night set point in cooling 26.0 °C 1 -
day set point in heating 20.0 °C 1 -
night set point in heating 18.0 °C 1 -
dIF relay 1 di erential 1.0 °C 1 -
dF2 relay 2 di erential 1.0 °C 2 =dIF
dS1 relay o set 0.0 °C 2 = 0
dSA analogue output o set 0.0 % rH 2 =0
humidi cation set point 50.0 % rH 1 -
dFH humidi cation di erential 5.0 % rH 1 -
Tab. 5.e
5.6 (T2A) automatic temperature control
only
This control mode is available on products with two relay outputs for
temperature control (ADCA******) and is used to have three di erent
types of automatic cooling/heating control. Typical applications: air-
conditioner plus boiler, air-conditioner/heat pump, condensing unit.
Once having selected the basic con guration using the dipswitches, the
three operating modes available are selected by parameter (Adc).
Dipswitch con guration:
dip1: OFF
dip2: ON
dip3: ON
Con guration 1 (AdC = 1)
For the control of a classic system with air-conditioner + boiler. The
controller sends to the start signal to one or other appliance-
Automatic operating mode is signalled on the display by the AUTO
symbol, next to the set point.
The analogue output is de ned for one function only, heating or cooling.
The selection is made using dipswitch 4 located on the rear.
The  gure illustrates operation:
DIP 4=ON
Temp.
10 V
0 V
dFA
dS1 dS1
dSA
dF2 dIF
Set point temperatura inverno/estate
Output
R2 R1
Fig. 5.i
DIP 4=OFF
Temp.
10 V
0 V
dFA
dS1 dS1
dSA
dF2 dIF
Set point temperatura inverno/estate
Output
R2 R1
Fig. 5.j
Cooling/heating control for air-conditioner/boiler systems. The analogue
output is associated with cooling or heating control, as set ny DIP 4 when
LE=2.
Parameters involved:
Code Description Default LE
Value or
link if LE
= 1
day set point
(same for cooling & heating)
20.0 °C 1 -
night set point
(same for cooling & heating)
18.0 °C 1 -
dIF relay 1 di erential 1.0 °C 1 -
dF2 relay 2 di erential 1.0 °C 2 = dIF
dFA analogue output di erential 1.0 °C 2 = dIF
dS1 relay 1 & 2 o set 0.5 °C 1 -
dSA analogue output o set 0.0 °C 2 = dS1
Tab. 5.f
