8. TECHNICAL SPECIFICATIONS
8.1 Technical speci cations
Power supply
24 Vac +10 to -15%, 50/60Hz, 1 VA
22 to 35 Vdc, 0.5W
Class 2 safety power supply
Min. cable cross-section 0.5 mm
2
.
Power supply compatible with compactSteam (G – G0)
Operating temperature
0T60 °C, 10 to 90% rH not-condensing
Storage temperature
-20T70 °C, 10 to 90% rH not-condensing
Environmental pollution
normal
Pollution
degree 2
Software class and structure
A
Type of action
1C
Index of protection
IP20
Ball pressure test temperature on plastic of front casing
125 °C
Classi cation according to protection against electric shock
2, to be integrated into class 1 or 2 appliances
Period of stress across the insulating parts
long
Immunity against voltage surges
category 2
Wire cross-section (mm
2
)
from 0.5 to 1.5 mm
2
Precision of inside temperature measurement
± 1 °C from 0 to 60 °C
Precision of outside temperature measurement
NTC (standard CAREL 10 kΩ) range –40T80 °C
precision ± 0.5 °C + sensor precision:
± 1 °C from 0 to 40 °C
± 1.5 °C from -40 to 0 °C and from 40 and 80 °C
0 to 10 V analogue output, not isolated, for proportional control
precision ±5%
max load 5 kΩ, max current 2 mA
Relay approval
EN60730-1: NO 1(1)A 250 Vac cos = 0.4, 100,000 cycles
UL-873: NO 1A resistive 24 Vac, 30 Vdc, 100,000 cycles
PILOT DUTY: 24 Vac, peak 15 A, continuous 1 A, 30,000 cycles
Precision of humidity measurement (in models where featured)
range 10 to 90%%
± 3% rH at 25 °C
± 5% rH 0 to 60 °C
Dimensions (mm):
135x86x36mm
Tab. 5.a
8.2 Wiring
Digital input Non-isolated version:
direct connection of the voltage-free contact; contact closing current: 3 to 5 mA.
Isolated version:
with external power supply to 24 Vac contact: class 2 safety external power supply separate from the 24
Vac power supply to the instrument
Outside temperature sensor connection
with standard CAREL sensor (10 K 25 °C B=3435):
Maximum length: 30 m, min. cable cross-section 0.5 mm
2
.
Digital input connection
Maximum length 10 m, min. cable cross-section 0.5 mm
2
.
Analogue output connection
Maximum length 10 m, min. cable cross-section 0.5 mm
2
.
Relay output connections:
Maximum length 30 m, cable cross-section from 1.5 to 2.5 mm
2
, class 2 reinforced insulation from the
instrument.
Basic insulation between the relays.
UL speci cations for connections:
Use copper wires approved for a temperature of 75 C.
Minimum cross-section AWG 22-14 rigid or  exible.
To tighten the terminals, apply a torque of 7 Lb/In for the black terminals (SAURO)
To use the instrument in compliance with UL-873, a load with a maximum voltage 24 Vac, class 2, can be
connected to the relay output.
Tab. 5.b
Warning: All the connections, except for the relays, must be
connected to very low voltage circuits with reinforced insulation.
