Carel Clima - 9.2 Software updates

36
ENG
clima +030220641 - rel. 1.0 - 07.12.2007
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
26 2 night temperature set point in cooling 10 40 26 C R/W
27 3 day temperature set point in heating 10 40 20 C R/W
28 4 night temperature set point in heating 10 40 18 C R/W
dIF 29 5 temperature di erential dIF 0 10 1 C R/W
dS1 30 6 temperature di erential dS1 -10 10 0 C R/W
dSA 31
7 temperature di erential dSA -10 10 0.0 C R/W
32 8 humidi cation set point 10 70 50 %rH R/W
33 9 dehumidi cation set point 10 70 70 %rH R/W
dFH 34 10 humidi cation di erential dFH 1 20 5 %rH R/W
dFd 35 11 dehumidi cation di erential dFd 1 20 5 %rH R/W
CAL+Int 36 12 inside temperature calibration -10 10 0 C R/W
CAL+ESt 37 13 outside temperature calibration -10 10 0 C R/W
CAL+HUn 38 14 humidity sensor calibration -15 15 0 %rH R/W
CtS 39 15 threshold for set point compensation in cooling 0 25 10 C R/W
Ctt 40 16 threshold for set point compensation in heating 0 25 10 C R/W
CdF 41 17 max di erential for set point compensation 0 20 2 C R/W
CSt 42 18 parameter for set point compensation -1 1 0 R/W
EHi 43 19 maximum water temperature for model T+H radiant 10 80 40 C R/W
ELo 44 20 minimum water temperature for model T+H radiant 0 50 10 C R/W
tHH
45 21 High water temperature limit in heating 15 80 45 C R/W
tHL
46 22 Low water temperature limit in heating 15 80 23 C R/W
tHH
47 23 High water temperature limit in cooling 5 35 30 C R/W
tHL
48 24 Low water temperature limit in cooling 5 35 10 C R/W
tAH
49 25 High room temperature limit in heating 15 40 24 C R/W
tAL
50 26 Low room temperature limit in heating 15 40 16 C R/W
tAH
51 27 High room temperature limit in cooling 5 35 30 C R/W
tAL
52 28 Low room temperature limit in cooling 5 35 16 C R/W
ddP
53 29
Dewpoint delta for adjusting the water
temp. set point
-20 20 0 C R/W
Tab. 9.c
9.2 Software updates
From release 2.3 to 2.4:
Resolved the communication problem between multiple instruments •
connected in a supervisor network with CAREL protocol
From release 2.4 to 2.5:
Resolved the communication problem involving the digital variables •
using the Modbus® protocol
Changed the maximum allowable limit of the temperature set point •
from 40 °C to 50 °C.
From release 2.5 to 2.6:
Increased the speed for reading the temperature + humidity sensor.•
Rearranged operation of T2A mode with AdC=2 and AdC=3.•
Changed the alarm signals.•
Improved errors management in Modbus®.•
Note: All the analogue variables (set point, di erential, sensor
calibration ...) are expressed in tenths if read with the CAREL
protocol, while they are expressed in hundredths if read with the Modbus®
protocol (example: 24.3 °C: CAREL supervisor = 243, Modbus® supervisor
= 2430)
