35
ENG
clima +030220641 - rel. 1.0 - 07.12.2007
par “CAREL sup
index”
“Modbus
index”
description min max def UOM R/W note
- 40 39 “Low water temperature alarm for model T+H rad.
0= not active - 1= active”
01- R
- 49 48 “Reading of dipswitch 4
0= o - 1= on”
01- R
- 50 49 “Reading of dipswitch 1
0= o - 1= on”
01- R
- 51 50 “Reading of dipswitch 2
0= o - 1= on”
01- R
- 52 51 “Reading of dipswitch 3
0= o - 1= on”
01- R
- 53 52 “Digital input reading
1= open - 0= closed “
01- R
Tab. 9.a
Integer variables
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
- 1 150
internal RTC reading in minutes
(e.g.: 13:13 equals 793 min.)
0 1439 - min R/W
- 3 152
status of the mode changeover timer
(day if in night mode, night if in day mode)
0 720 - min R/W
AUt 6 130 parameter AUt 0 7 0 R/W
dI 7 131 parameter dI 0 4 0 R/W
dyS 8 132 parameter dyS 1 4 1 R/W
SLP 9 133
duration of the mode changeover timer
(day if in night mode, night if in day mode)
0 12 8 h R/W
- 10 134 day band threshold 0 1439 480 min R/W
- 11 135 night band threshold 0 1439 1200 min R/W
Add 12 136 485 serial address 1 207 1 R
LOC 13 137 parameter LOC 0 2 0 R/W
nEd 14 138 parameter nEd 0 100 0 % R/W
- 15 139 con guration set by dip1, 2 & 3 0 7 0 R/W
SFH 16 140 humidi cation/dehumidi cation & day/night status parameter 0 2 0 - R/W
PS 17 141 parameter PS 0 999 0 R/W
tIn 18 142 parameter tIn 1 100 10 min. R/W
tr 19 143 parameter tr (OFF = 0) 0 255 0 min. R/W
SEr 20 144 parameter SEr 0 5 1 R/W
Tab. 9.b
Analogue variables
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
- 1 35 inside NTC temperature sensor -40 70 - C R
the calibration value is
not added
- 2 36 remote NTC temperature sensor (water system) -40 80 - C R
the calibration value is
not added
- 3 37 minimum inside temperature recorded from unit ON -40 70 - C R
the calibration value is
not added
- 4 38 maximum inside temperature recorded from unit ON -40 70 - C R
the calibration value is
not added
- 5 39 minimum water temperature recorded from unit ON -40 80 - C R
the calibration value is
not added
- 6 40 maximum water temperature recorded from unit ON -40 80 - C R
the calibration value is
not added
- 7 41 digital temperature sensor -40 70 - C R
the calibration value is
not added
- 8 42 digital humidity sensor value 0 99 - %rH R
- 13 47 analogue output value 0 100 - R
- 14 48 PWM value for cooling 0 100 - R/W W if LIn=1
- 15 49 PWM value for heating 0 100 - R/W W if LIn=1
- 16 50 PWM value for humidi cation 0 100 - R/W W if LIn=1
21 55 set point calculated for radiant system water 5 80 - C R
22 56 dewpoint calculated - - - C R
23 57 maximum temperature limit for water set, tHH calculated tHL tHH - C R
24 58 minimum temperature limit for water set, tHL calculated tHL tHH - C R
25 1 day temperature set point in cooling 10 40 24 C R/W
