3.5 Display pages
No
1st variable
(1st part of line 1)
2nd variable
(2nd part of line 1)
3rd variable
(2nd line)
Remarks
Applications
BCDEF
Phase sequence
For reverse phase sequence, the alarm triangle will be
shown on every page
x x x x x x
1 Total kWh W sys x x x x x x
1b Total kWh (-) “NEG” Active energy exported +
2 Total kVarh kvar sys + +
+ + T
3 PF sys Hz C, -C, L, -L shown, depending on the quadrant x x x x x
4 PF L1 PF L2 PF L3 C, -C, L, -L shown, depending on the quadrant x x x x
5 A L1 A L2 A L3 x x x x
6 V L1-2 V L2
-3 V L3-1 x x x
7 V L1 V L2 V L3 x x
8 “thd” “L1” THD VL1-N x x x x x
9 “thd” “L2” THD VL2-N x x x x x
10 “thd” “L3” THD VL3-N x x x x x
11 “thd” “L1” THD
A L1 x x x x x
12 “thd” “L2” THD A L2 x x x x x
13 “thd”
“L3” THD A L3 x x x x x
14 “thd” “L1” THD VL1-2 x x x x x
15 “thd” “L2” THD VL2-3 x x x x x
16 “thd” “L3” THD VL3
-1 x x x x x
17 “A n” A n x x x x x
18 “op. hours” (rel. to kWh+) h x x x x
19 “op. hours” (rel. to kWh-)h- x
Tab. 3.g
Notes:
x = available
+ = only positive kVarh values are measured (kVar sys is the algebraic sum of the phase kVar values)
T = positive and negative kVarh values are summed together and measured by the same kVarh counter.
(kVar sys is the sum of the absolute values of each phase kVar). The phase
kVar values are displayed with the correct sign.
3.6 Other information available on the display
Type Line 1 Line 2 Remarks
Meter information 1Y. 2007 r.A0 Year of manufacture and rmware revision
Meter information 2 value LEd (kWh) kWh per LED pulse
Meter information 3SYS [3P.n] value System and connection type
Meter information 4Ct rAt. value Current transformer ratio
Meter information 5Ut rAt. value Voltage transformer ratio
Meter information 6 PuLSE (kWh)
value Pulse output: kWh per pulse
Meter information 7 Add value Serial communication address
Meter information 8 value Sn Secondary address (M-bus protocol)
Tab. 3.h
