Avvertenze:
il parametro non ha effetto per i regolatori ad un’uscita;
nei controlli con numero di serie minore di 100.000 la
rotazione è disabilitata nel funzionamento speciale
(C33=1) (per i controlli con numero di serie maggiore
di 100.000 vedere nota seguente);
nei modelli a due uscite(W), la rotazione è standard
anche per C11=2 o 3;
il collegamento nella configurazione 2+2 è il seguente:
OUT1 = Comp.1, OUT2 = Valv.1, OUT3 = Comp. 2,
OUT4 = Valv. 2.
Nota per la nuova versione
A partire dal numero di serie maggiore di 100.000 sono dispo-
nibili altre quattro nuove rotazioni, in aggiunta alle tre già
esistenti (attive nei modelli Z e A):
C11=4 ruotano uscite 3 e 4, NON ruotano uscite 1 e 2;
C11=5 ruotano uscite 1 e 2, NON ruotano uscite 3 e 4;
C11=6 ruotano uscite 1 e 2, ruotano uscite 3 e 4;
C11=7 ruotano uscite 2, 3 e 4, NON ruota uscita 1.
Con C33=1 le rotazioni sono valide per tutti i modi. Esse saranno
abilitate anche in funzionamento speciale; l’utente dovrà pre-
stare particolare attenzione alla programmazione dei parametri
perché il controllo farà ruotare le uscite secondo la logica sopra
indicata, indipendentemente dal fatto che esse siano uscite di
regolazione (anche PWM) o di allarme.
Esempio a: se si hanno due uscite di allarme e due di regolazio-
ne, è necessario scegliere la rotazione in modo tale da far ruotare
solamente le uscite di regolazione.
Esempio b: se si vuole controllare un chiller a tre compressori,
si potrà utilizzare la rotazione “7”, riservando le uscite 2, 3 e 4 ai
compressori, mentre l’uscita 1 potrà essere non collegata oppure
impiegata come uscita ausiliaria o uscita di allarme.
Important:
the parameter does not operate in single-output controllers;
in the controllers with serial number below 100,000
rotation is not operative in the special mode of operation
(C33=1) (for the controllers with serial number above
100,000 see note below)
in two-output models (W), the rotation is a standard
feature also when C11=2 or 3;
connection in the 2+2 configuration is as follows:
OUT1 = Comp.1, OUT2 = Valve 1, OUT3 = Comp.2,
OUT4 = Valve 2
Important: new versions
All controllers model Z and A whose serial number is above
100,000 come with the possibility of setting four new rota-
tions besides the existing ones:
C11=4 rotation of outputs 3 and 4, NO rotation for
outputs 1 and 2;
C11=5 rotation of outputs 1 and 2; NO rotation of
outputs 3 and 4;
C11=6 rotation of output 1 and 2; rotation of output 3 and 4;
C11=7 rotation of output 2, 3 and 4; NO rotation of output 1.
When C33=1 (special mode of operation), rotations become
operative for any mode. Pay attention when programming the
parameters as the controllers make the outputs rotate according
to the logic described above, no matter what the outputs are
dedicated (control, PWM or alarm outputs).
Example a: if your instrument has two alarm outputs and two
control outputs, the rotation should be selected so as to involve
exclusively the control outputs.
Example b: if you need to control a three-compressor chiller,
you can choose rotation “7” and dedicate outputs 2, 3 and 4
to the compressors. Output 1 can be used as auxiliary or alarm
output.
24
