10
dima di foratura
drilling template
71x29 mm
34.4
70.5
79
76.2
80.6
38.6
Fig. 2. a
1
2
Fig. 2. b
IROPZ48500:
Interfaccia scheda seriale RS485
Serial board interface RS485
IROPZKEY**:
Chiave di programmazione
Programming key
1
Fig. 2. c
110
70
60
46
Fig. 2. d
IROPZ485S0:
Interfaccia scheda
seriale RS485
intelligente
Smart serial board
interface RS485
IROPZKEY**:
Chiave di
programmazione
Programming key
IROPZKEY**:
Chiave di
programmazione
Programming key
IROPZSER30:
Interfaccia scheda
seriale RS485
Serial board
interface RS485
Fig. 2. e
ENG
ir33 universale +030220801 - rel. 1.0 - 16.04.2008
2. INSTALLATION
2.1 IR33: panel mounting and dimensions
2.1.1 IR33 optional connections
2.2 DN33: DIN rail mounting and dimensions
2.2.1 DN33 optional connections
