Carel IR33D7LR20 User Manual

45
ENG
ir33 universale +030220801 - rel. 1.0 - 16.04.2008
Operating temperature IR33xxxxxx: -10T60 °C
DN33x(V,W,Z,D,A,B,E)7LR20: -10T55°C
DN33x(V,W,Z,D,A,B,E)7Hx(R,B)20: -10T50°C
Operating humidity <90% rH non-condensing
Storage temperature -20T70 °C
Storage humidity <90% rH non-condensing
Front panel index of protection IR33: assembly on smooth and indeformable panel with IP65 gasket
DN33: front panel IP40, complete controller IP20
Construction of control device Integrated electronic control device
Environmental pollution 2 normal
PTI of the insulating materials Printed circuits 250, plastic and insulating materials 175
Period of stress across the insulating parts Long
Class of protection against voltage surges Category 2
Type of action and disconnection 1B relay contacts (microswitching)
Classi cation according to protection against electric shock Class 2 when appropriately integrated
Device designed to be hand-held or integrated
in hand-held devices
No
Software class and structure Class A
Front panel cleaning Only use neutral detergents and water
Carel serial network interface External, available on all models
Programming key Available on all models
Type of connection Size Max current
Connections model relays/ SSR power supply probes
IR33x(V,W,Z,D,A,B,E)7x(H,L)x(R,B)20
DN33x(V,W,Z,A,B,E)7x(H,L)x(R,B)20
plug-in plug-in plug-in for cables from
0.5 to 2.5 mm
2
12A
Correct sizing of the power and connection cables between the controller and the loads is the responsibility of the installer.
In the max load and max operating temp. conditions, the cables used must be suitable for operation up to 105°C.
Case plastic IR33x(V,W,Z,D,A,B,E)7x(H,L)x(R,B)20
DN33x(V,W,Z,A,B,E)7x(H,L)x(R,B)20
dimensions IR33:34.4x76.2x79mm
DN33:111x70x60
mounting
depth
IR33: 70.5mm
DN33: 60mm
Assembly IR33: on smooth and indeformable panel DN33 :DIN rail IR33 :side fastening brackets, to be pressed in fully
drilling template IR33:dimensions 28.8±0.2 x 70.8±0.2mm
DN33(display):dimensions 28.8±0.2 x 70.8±0.2mm
Display digits 3 digit LED
display from –99 to 999
operating status indicated with graphic icons on the display
Keypad 4 silicone rubber buttons
9.2 Cleaning the controller
When cleaning the controller do not use ethanol, hydrocarbons (petrol), ammonia and by-products. Use neutral detergents and water.
9.3 Product codes
CODE Description
Flush mount DIN rail mounting
IR33V7HR20 DN33V7HR20 2 NTC/PTC,PT1000 input, 1 relay, buzzer, IR receiver, 115/230V
IR33V7HB20 DN33V7HB20 2 NTC/PTC,PT1000 input, 1 relay , buzzer, IR receiver, RTC, 115/230V
IR33V7LR20 DN33V7LR20 2 NTC/PTC,PT1000 input, 1 relay , buzzer, IR receiver, 12/24V
IR33W7HR20 DN33W7HR20 2 NTC/PTC,PT1000 input, 2 relays, buzzer, IR receiver, 115/230V
IR33W7HB20 DN33W7HB20 2 NTC/PTC,PT1000 input, 2 relays, buzzer , IR receiver, RTC, 115/230V
IR33W7LR20 DN33W7LR20 2 NTC/PTC,PT1000 input, 2 relays, buzzer, IR receiver, 12/24V
IR33Z7HR20 DN33Z7HR20 2 NTC/PTC,PT1000 input, 4 relays, buzzer, IR receiver, 115/230V
IR33Z7HB20 DN33Z7HB20 2 NTC/PTC,PT1000 input, 4 relays , buzzer, IR receiver, RTC, 115/230V
IR33Z7LR20 DN33Z7LR20 2 NTC/PTC,PT1000 input, 4 relays , buzzer, IR receiver, 12/24V
IR33A7HR20 DN33A7HR20 2 NTC/PTC,PT1000, 4 SSR, buzzer, IR receiver, 115/230V
IR33A7HB20 DN33A7HB20 2 NTC/PTC,PT1000 input, 4 SSR, BUZZER, IR receiver, RTC, 115/230V
IR33A7LR20 DN33A7LR20 2 NTC/PTC,PT1000 input, 4 SSR, buzzer, IR receiver, 12/24V
IR33D7HR20 - 2 NTC/PTC,PT1000 input, 1 SSR, buzzer, IR receiver, 115/230V
IR33D7HB20 - 2 NTC/PTC,PT1000 input, 1 SSR, buzzer, IR receiver, RTC, 115/230V
IR33D7LR20 - 2 NTC/PTC,PT1000 input, 1 SSR, buzzer, IR receiver, 12/24V
IR33B7HR20 DN33B7HR20 2 NTC/PTC,PT1000 input, 1 relay + 1 AO, buzzer, IR receiver, 115/230V
IR33B7HB20 DN33B7HB20 2 NTC/PTC,PT1000 input, 1 relay + 1 AO, buzzer, IR receiver, RTC, 115/230V
IR33B7LR20 DN33B7LR20 2 NTC/PTC,PT1000 input, 1 relay + 1 AO, buzzer, IR receiver, 12/24V
IR33E7HR20 DN33E7HR20 2 NTC/PTC,PT1000 input, 2 relays + 2 AO, buzzer, IR receiver, 115/230V
IR33E7HB20 DN33E7HB20 2 NTC/PTC,PT1000 input, 2 relays + 2 AO, buzzer, IR receiver, RTC, 115/230V
IR33E7LR20 DN33E7LR20 2 NTC/PTC,PT1000 input, 2 relays + 2 AO, buzzer, IR receiver, 12/24V
IROPZKEY00 Programming key
IROPZKEYA0 Programming key with power supply
IROPZ48500 RS485 serial interface
IROPZ485S0 RS485 serial interface with automatic recognition of TxRx+ & TxRx-
IROPZSER30 RS485 serial card for DN33
CONV0/10A0 Analogue output module
CONV0NOFF0 ON/OFF output module
IRTRUES000 Remote control
