ir33 universale +030220801 - rel. 1.0 - 16.04.2008
Par. Description Note Def Min Max UoM Type CAREL SVP ModBus® R/W Icon
AL4 Date – time of alarm 4 (press Set)
(y=year ,M=month,d=day,h=hours,m=minutes)
-- -- I - - R
y AL4_y = year of alarm 4 0 0 99 year I 127 200 R
M AL4_M = month of alarm 4 0 1 12 month I 128 201 R
d AL4_d = day of alarm 4 0 1 31 day I 129 202 R
h AL4_h = hours of alarm 4 0 0 23 hours I 130 203 R
m AL4_m = minutes of alarm 4 0 0 59 mins. I 131 204 R
E AL4_t = type of alarm 4 0 0 99 - I 132 205 R
ton Switch device on (press Set)
(d=day ,h=hour, m=minutes)
-- -- - - - R
d tON_d = on day 0 0 11 day I 133 206 R/W
h tON_h = on hours 0 0 23 hours I 134 207 R/W
m tON_m = on minutes 0 0 59 mins. I 135 208 R/W
to Switch device o (press Set)
(d=day ,h=hour, m=minutes)
-- -- - - - R
d tOFF_d = o day 0 0 11 day I 136 209 R/W
h tOFF_h = o hours 0 0 23 hours I 137 210 R/W
m tOFF_m = o minutes 0 0 59 mins I 138 211 R/W
tc Date – time (press Set)
(y=year, M=month, d=day of month, u=day of week,
h=hours, m=minutes)
-- -- - - - R
y Date: year 0 0 99 year I 28 101 R/W
M Date: month 1 1 12 month I 29 102 R/W
d Date: day 1 1 31 day I 30 103 R/W
u Date: day of the week (Monday, ...) 1 1 7 day I 31 104 R/W
h Hours 0 0 23 hours I 32 105 R/W
M Minutes 0 0 59 mins. I 33 106 R/W
(*) Functions active starting from software version higher than 1.0.
The default, minimum and maximum values of the temperature parameter refer to the unit of measure in °C. If changing the unit of measure, the
corresponding values must be entered.
7.1 Variables only accessible via serial connection
Description Def Min Max UoM Typ. CAREL SVP ModBus®(*) R/W Description
Reading of probe 1 0 0 0 °C/°F A 1 2 R_TYPE Reading of probe 1
Reading of probe 2 0 0 0 °C/°F A 2 3 R_TYPE Reading of probe 2
Status of output 1 0 0 1 - D 139 1 R_TYPE Status of relay 1
Status of output 2 0 0 1 - D 140 2 R_TYPE Status of relay 2
Status of output 3 0 0 1 - D 141 3 R_TYPE Status of relay 3
Status of output 4 0 0 1 - D 142 4 R_TYPE Status of relay 4
Status of digital input 1 0 0 1 - D 144 6 R_TYPE Status of digital input 1
Status of digital input 2 0 0 1 - D 145 7 R_TYPE Status of digital input 2
Probe 2 fault alarm 0 0 1 - D 148 10 R_TYPE Probe 2 fault alarm
Immediate external alarm 0 0 1 - D 149 11 R_TYPE Immediate external alarm
High temperature alarm 0 0 1 - D 150 12 R_TYPE High temperature alarm
Low temperature alarm 0 0 1 - D 151 13 R_TYPE Low temperature alarm
Delayed external alarm 0 0 1 - D 152 14 R_TYPE Delayed external alarm
Immediate external alarm with
manual reset
0 0 1 - D 153 15 R_TYPE Immediate external alarm with
manual reset
RTC fault alarm 0 0 1 - D 154 16 R_TYPE RTC fault alarm
EEPROM unit parameters alarm 0 0 1 - D 155 17 R_TYPE EEPROM unit parameters alarm
EEPROM operating parameters alarm 0 0 1 - D 156 18 R_TYPE EEPROM operating parameters alarm
Maximum time in calculation of
PID parameters
0 0 1 - D 157 19 R_TYPE Maximum time in calculation of
PID parameters
PID gain null 0 0 1 - D 158 20 R_TYPE PID gain null
PID gain negative 0 0 1 - D 159 21 R_TYPE PID gain negative
Integral & derivative time negative 0 0 1 - D 160 22 R_TYPE Integral & derivative time negative
Maximum time in calculation of
continuous gain
0 0 1 - D 161 23 R_TYPE Maximum time in calculation of
continuous gain
Starting situation not suitable 0 0 1 - D 162 24 R_TYPE Starting situation not suitable
Switch controller On/O 0 0 1 - D 174 36 R_W_TYPE Switch controller On/O
(*) Functions active starting from software version higher than 1.0.
Type of variable : A =analogue, D=digital, I=integer
SVP= variable address with CAREL protocol on 485 serial card.
ModBus® : variable address with ModBus® protocol on 485 serial card.
The selection between CAREL and ModBus® protocol is automatic. For both of them the speed is xed to 19200 bit/s.
All the devices connected to the same network must feature the same serial parameters: - 8 data bit;
- 1 start bit;
- 2 stop bit;
- no parity check;
- 19200 baud rate.
To Next Page
