ir33 universale +030220801 - rel. 1.0 - 16.04.2008
Par. Description Note Def Min Max UoM Typ. CAREL SVP ModBus® R/W Icon
c48 Activation of output 4 -100 -100 100 % I 77 150 R/W 4
c49 Di erential/logic of output 4 25 -100 100 % I 78 151 R/W 4
d46 Activation restriction for output 4 3 0 3 - I 79 152 R/W 4
d47 Deactivation restriction for output 4 0 0 4 - I 80 153 R/W 4
d48 Minimum value of modulating output 4(*) 0 0 100 % I 81 154 R/W 4
d49 Maximum value of modulating output 4(*) 100 0 100 % I 82 155 R/W 4
c50 Disable keypad and remote control 1 0 2 - I 83 156 R/W
c51 Code for enabling the remote control
0=Programming from remote control without code
1 0 255 - I 84 157 R/W
c52 Display
0=Probe 1
1=Probe 2
2=Digital input 1
3=Digital input 2
0 0 3 - I 85 158 R/W
c53 Buzzer
0=Enabled
1=Disabled
0 0 1 - D 171 33 R/W
c56 Delay at start-up 0 0 255 s I 86 159 R/W
c57 Soft start(*) 0 0 99 min I 87 160 R/W
c62 ti_PID 600 0 999 s I 88 161 R/W TUNING
c63 td_PID 0 0 999 s I 89 162 R/W TUNING
c64 Auto-Tuning
0=Disabled
1=Enabled
0 0 1 - D 172 34 R/W TUNING
c66 Enabling direct threshold(*)
Validity: c0 =1,2
-50 -50 150 °C/°F A 21 22 R/W
c67 Enabling reverse threshold(*)
Validity: c0 =1,2
150 -50 150 °C/°F A 22 23 R/W
c68 Enable Cut o operation
0=Cut o enabled
1=Cut o disabled
0 0 1 - D 173 35 R/W
P70 Enable operating cycle
0=Disabled
1=Keypad
2=Digital input
3=RTC
0 0 3 - I 97 170 R/W
P71 Operating cycle: duration of step 1 0 0 200 min I 98 171 R/W
P72 Operating cycle: temperature set point step 1 0 -50 150 °C/°F A 23 24 R/W
P73 Operating cycle: duration of step 2 0 0 200 min I 99 172 R/W
P74 Operating cycle: temperature set point step 2 0 -50 150 °C/°F A 24 25 R/W
P75 Operating cycle: duration of step 3 0 0 200 min I 100 173 R/W
P76 Operating cycle: temperature set point step 3 0 -50 150 °C/°F A 25 26 R/W
P77 Operating cycle: duration of step 4 0 0 200 min I 101 174 R/W
P78 Operating cycle: temperature set point step 4 0 -50 150 °C/°F A 26 27 R/W
P79 Operating cycle: duration of step 5 0 0 200 min I 102 175 R/W
P80 Operating cycle: temperature set point step 5 0 -50 150 °C/°F A 27 28 R/W
AL0 Date – time of alarm 0 (press Set)
(y=year ,M=month,d=day,h=hours,m=minutes)
-- - - -- - R
y AL0_y = year of alarm 0 0 0 99 year I 103 176 R
M AL0_M = month of alarm 0 0 1 12 month I 104 177 R
d AL0_d = day of alarm 0 0 1 31 day I 105 178 R
h AL0_h = hours of alarm 0 0 0 23 hours I 106 179 R
m AL0_m = minutes of alarm 0 0 0 59 minutes I 107 180 R
E AL0_t = type of alarm 0 0 0 99 - I 108 181 R
AL1 Date – time of alarm 1 (press Set)
(y=year ,M=month,d=day,h=hours,m=minutes)
-- - - -- - R
y AL1_y = year of alarm 1 0 0 99 year I 109 182 R
M AL1_M = month of alarm 1 0 1 12 month I 110 183 R
d AL1_d = day of alarm 1 0 1 31 day I 111 184 R
h AL1_h = hours of alarm 1 0 0 23 hours I 112 185 R
m AL1_m = minutes of alarm 1 0 0 59 minutes I 113 186 R
E AL1_t = type of alarm 1 0 0 99 - I 114 187 R
AL2 Date – time of alarm 2 (press Set)
(y=year ,M=month,d=day,h=hours,m=minutes)
-- - - -- - R
y AL2_y = year of alarm 2 0 0 99 year I 115 188 R
M AL2_M = month of alarm 2 0 1 12 month I 116 189 R
d AL2_d = day of alarm 2 0 1 31 day I 117 190 R
h AL2_h = hours of alarm 2 0 0 23 hours I 118 191 R
m AL2_m = minutes of alarm 2 0 0 59 minutes I 119 192 R
E AL2_2 = type of alarm 2 0 0 99 - I 120 193 R
AL3 Date – time of alarm 3 (press Set)
(y=year ,M=month,d=day,h=hours,m=minutes)
-- - - -- - R
y AL3_y = year of alarm 3 0 0 99 year I 121 194 R
M AL3_M = month of alarm 3 0 1 12 month I 122 195 R
d AL3_d = day of alarm 3 0 1 31 day I 123 196 R
h AL3_h = hours of alarm 3 0 0 23 hours I 124 197 R
m AL3_m = minutes of alarm 3 0 0 59 minutes I 125 198 R
E AL3_t = type of alarm 3 0 0 99 - I 126 199 R
