ir33plus +0300028EN rel. 1.1 - 05.05.2017
User Par. Description Models Def Min Max UOM Type CAREL SVP ModBus® R/W
CnF
C H0 Serial address MSYFCH 1 0 207 - I 60 160 R/W
C H1 AUX output con guration
0 = normally energised alarm
1 = normally de-energised alarm
2 = auxiliary
3 = light
4 = auxiliary evaporator defrost
5 = pump down valve
6 = condenser fan
7 = delayed compressor
8 = auxiliary with deactivation when OFF
9 = light with deactivation when OFF
10 = no function
11 = reverse with neutral zone
12 = second compressor step
13 = second compressor step with rotation
CH 1 0 13 - I 61 161 R/W
C H2 Disable keypad functions MSYFCH 1 0 6 - I 62 162 R/W
C H4 Buzzer: 0/1=enabled/disabled MSYFCH 0 0 1 - D 53 53 R/W
C H5 AUX2 output con guration: see H1 H 3 0 13 - I 64 164 R/W
C H6 Terminal keypad lock con guration
0 = all buttons enabled
MSYFCH 0 0 255 - I 65 165 R/W
C H7 Keypad: 0 = standard; 1 = modi ed MSYFCH 0 0 1 - D 54 54 R/W
C H8 Output switched with scheduler 0 = Light; 1= AUX MSYFCH 0 0 1 - D 60 60 R/W
C H9 Set point variation with scheduler 0/1 = no/yes MSYFCH 0 0 1 - D 61 61 R/W
C Hdn Number of default parameter sets available MSYFCH 0 0 6 - I 137 237 R/W
C Hdh Anti-sweat heater o set
0 = anti-sweat heater function disabled (°C)
32 = anti-sweat heater function disabled (°F)
MSYFCH 0 -50 200 °C/°F A 37 37 R/W
C HrL Remote light relay status on Master: 0 = disabled MSYFCH 0 0 1 - D 62 62 R/W
C HrA Remote AUX relay status on Master: 0 = disabled MSYFCH 0 0 1 - D 63 63 R/W
C HSA Remote controller alarms on Master: 0 = disabled MSYFCH 0 0 1 - D 64 64 R/W
C In Type of unit
0 = Normal
1 = Master
2…6 = Slave 1 to 5
MSYFCH 0 0 6 - I 138 238 R/W
User Par. Description Models Def Min Max UOM Type CAREL SVP ModBus® R/W
HcP
C HAn Number of HA alarms MSYFCH 0 0 15 - I 67 167 R
C HA…
HA2
HA HACCP alarms activated (press Set) MSYFCH - - - - - - - R
y__ Alarm 1 to 3 - Year - 0 0 99 years I 70/76/82 170 R
M__ Alarm 1 to 3 - Month - 0 1 12 month I 71/77/83 171 R
d__ Alarm 1 to 3 - Day of the month - 0 1 7 day I 72/78/84 172 R
h__ Alarm 1 to 3 - Hour - 0 0 23 hour I 73/79/84 173 R
n__ Alarm 1 to 3 - Minute - 0 0 59 minute I 74/80/85 174 R
t__ Alarm 1 to 3 - Duration - 0 0 99 hour I 75/81/86 175 R
C HFn Number of HF alarms MSYFCH I 68 176…181 R
C HF…HF2 HF HACCP alarms activated (press Set) MSYFCH - - - - I - - R
y__ Alarm 1 to 3 - Year 0 0 99 years I 88/94/100 188 R
M__ Alarm 1 to 3 - Month 0 1 12 month I 89/95/101 189 R
d__ Alarm 1 to 3 - Day of the month 0 1 7 day I 90/96/102 190 R
h__ Alarm 1 to 3 - Hour 0 0 23 hour I 91/97/103 191 R
n__ Alarm 1 to 3 - Minute 0 0 59 minute I 92/98/104 192 R
t__ Alarm 1 to 3 - Duration 0 0 99 hour I 93/99/105 193 R
C Htd HACCP alarm delay
0 = Monitoring disabled
MSYFCH 0 0 250 min I 69 169 R/W
