Carel SmartCella 3PH Quick Guide

22
ENG
“SmartCella 3PH” +0500119IE - rel. 1.3 - 21.11.2019
Symbol Code Parameter UOM Type Min. Max. Def.
d0 Type of defrost
0: heater by temperature
1: hot gas by temperature
2: heater by time (Ed1, Ed2 not shown)
3: hot gas by time (Ed1, Ed2 not shown)
4: heater with thermostat by time (Ed1, Ed2 not shown)
fl a g C 0 4 0
dI Maximum time between consecutive defrosts
0= defrost not performed
ore F 0 250 8
dt1 End defrost temperature probe 2 °C/°F F -50 200 4.0
dt2 End defrost temperature probe 3 °C/°F F -50 200 4.0
dP1 Maximum defrost duration min F 1 250 30
dP2 Maximum aux evaporator defrost duration min F 1 250 30
d3 Defrost activation delay min C 0 250 0
d4 Defrost at start-up
0: disabled 1: enabled
fl a g C 0 1 0
d5 Defrost delay at start-up (if d4=1) or from dI min C 0 250 0
d6 Display on terminal during defrost
0: temperature alternating with dEF
1: display disabled
2: dEF
-C021
dd Dripping time after defrost (fans off ) min F 0 15 2
d8 High temperature alarm bypass time after defrost (and door open) ore F 0 250 1
d8d Alarm bypass time after door open min C 0 250 0
d9 Defrost priority over compressor protectors
0: protection times c1, c2 and c3 applied
1: protection times c1, c2 and c3 ignored
fl a g C 0 1 0
d/1 Display defrost probe 1 °C/°F F - - -
d/2 Display defrost probe 2 °C/°F F - - -
dC Time base for defrost
0: dI in hours, dP1 and dP2 in minutes
1: dI in minutes, dP1 and dP2 in seconds
fl a g C 0 1 0
d10 Defrost time with Running time
0= function disabled
ore C 0 250 0
d11 Running time defrost temperature threshold °C/°F C -20 20 1.0
d12 Advanced defrosts -C030
dn Nominal defrost duration - C 1 100 65
dH Proportional factor for variation of dI - C 0 100 50
A0 Alarm and fan diff erential °C/°F C 0.1 20 2.0
A1 Alarm thresholds (AL and AH) relative to the set point or absolute
0: AL and AH thresholds relative to the set point
1: AL and AH absolute thresholds
fl a g C 0 1 0
AL Low temperature alarm threshold °C/°F F -50 200 0.0
AH High temperature alarm threshold °C/°F F -50 200 0.0
Ad High and low temperature alarm delay min F 0 250 120
A4 Confi guration of digital input 1 (DI1)
0: Not active
1: Immediate external alarm
2: Delayed external alarm
3: If model M select probes
3: Other models enable defrost
4: Start defrost
5: Door switch with comp. and fans off
6: Remote ON/OFF
7: Curtain switch
8: Low pressure switch
9: Door switch with fans off
10: Direct/reverse operation
11: Light sensor
12: Activate aux output
13: Door switch with compressor and fans off , light not managed
14: Door switch with fans off and light not managed
-C0145
A5 Confi guration of digital input 2 (DI2) / As per A4 - C 0 14 1
A6 Stop compressor on external alarm min C 0 100 0
A7 Digital alarm input delay min C 0 250 0
A8 Enable alarms Ed1 and Ed2 (defrost ended by timeout)
0: Ed1 and Ed2 signals enabled
1: Ed1 and Ed2 signals disabled
fl a g C 0 1 0
A9 Confi guration of digital input 3 (DI3) / As per A4 - C 0 14 0
Ac High condenser temperature alarm threshold °C/°F C 0.0 200 70
AE High condenser temperature alarm diff erential °C/°F C 0.1 20 10
Acd High condenser temperature alarm delay min C 0 250 0
AF Light sensor OFF time s C 0 250 0
ALF Frost protection alarm threshold °C/°F C -50 200 -5
AdF Frost protection alarm delay min C 0 15 1
