Symbol Code Parameter UOM Type Min. Max. Def.
F0 Fan management
0: always on
1: activation based on Sd-Sv (diff erence between virtual probe and evaporator
temperature)
2: activation based on Sd (evaporator temperature)
fl a g C 0 2 0
F1 Fan activation temperature (only with F0=1 or 2) °C/°F F -50 200 5
F2 Evaporator fans with compressor off
0: see F0
1: always off
fl a g C 0 1 1
F3 Evaporator fans during defrost
0: on
1: off
fl a g C 0 1 1
Fd Post-dripping time (fans off ) min F 0 15 1
F4 Condenser fan deactivation temperature °C/°F C -50 200 40
F5 Condenser fan activation diff erential °C/°F C 0.1 20 5
H0 Serial address - C 0 207 1
H1 AUX1 output confi guration
0: normally energised alarm
1: normally de-energised alarm
2: auxiliary
3: light
4: auxiliary evaporator defrost
5: pump down valve
6: condenser fan
7: delayed compressor
8: auxiliary with deactivation when OFF
9: light with deactivation when OFF
10: no function
11: reverse with neutral zone
12: second compressor step
13: second compressor step with rotation
fl ag C 0 13 3
H2 Disable keypad/IR
Parameter “H2” LIGHT ON/OFF AUX HACCP PRG/MUTE (mute) UP/CC DOWN/DEF SET Change parameters F Change set point
0••
1
2••
3
4• •••
5• ••••
6••••
Keyboard functionality
"•" = Disabled
fl a g C 0 6 1
H3 Parameter not used - C 0 255 0
H4 Buzzer 0: enabled 1: disabled fl ag C 0 1 0
H5 AUX 2 output confi guration (as for H1) fl ag C 0 13 1
H6 Terminal keypad lock confi guration - C 0 255 0
H8 switched with time band
0: light 1: Aux
fl a g C 0 1 0
H9 Set point variation with time band
0: Set point variation with time band disabled
1: Set point variation with time band enabled
fl a g C 0 1 0
Hdh Anti-sweat heater off set °C/°F C -50 200 0
Tab. 3.a
